8 PM-102 specifications
Engine
The Caterpillar ® 3126B engine is a six
cylinder, turbocharged air-to-air
after-cooled diesel engine. The engine
meets U.S. EPA Tier 2 and European
EU Stage II engine emission
regulations.
Engine Cat ® 3126B
Gross Power kW hp
SAE J1995 168 225
Net Power kW hp
ISO 9249 156 209
EEC 80/1269 156 209
SAE J1349 151 203
Specifications
Bore 110 mm 4.3"
Stroke 127 mm 5.0"
Displacement 7.2 liters 442 in 3
■ The power ratings apply at a rated
speed of 2200 RPM when tested
under the reference conditions for the
specific standard.
■ The net power advertised is the
power available at the flywheel when
the engine is equipped with an
alternator, air cleaner, muffler and
fan.
■ Derating is not required up to an
altitude of 3000 m (9850').
■ Cold mode starting aid, dual fuel
filters with water separator and air
compressor are standard.
Propel System
Hydrostatic drive with hydraulic flow
provided by a variable displacement
piston-type pump. Drive motors with
planetary gear reduction on each track
or wheel provides balanced tractive
effort. Machine can be equipped with
either a track or wheeled undercarriage.
Features
■ A variable displacement, piston-type
pump with electronic displacement
control supplies pressurized flow.
■ Positive traction control valve
provides equal hydraulic oil flow to
each drive motor to increase tractive
effort in hard cutting.
■ Drive motors have two swashplate
positions allowing operation at either
maximum torque throughout the
entire milling speed range or at a
faster travel speed for moving around
the job site.
■ Gear selection controlled electrically
by a two-position switch on the
operator’s console.
■ Infinitely variable machine speed and
direction of travel controlled by
propel lever and speed dial.
■ Load control system, controlled by
Electronic Control Module (ECM),
matches propel speed to load on the
engine for maximum production.
■ Track undercarriage – tracks are
720 mm (28.3") long, 225 mm (8.8")
wide and feature replaceable
polyurethane track pads.
■ Wheel undercarriage – wheels have a
diameter of 660 mm (25.9") and are
260 mm (10.2") wide.
Max. Speeds (forward and reverse):
Track undercarriage
Operating 27 mpm - 89 fpm
Travel 4.1 km/h - 2.5 mph
Wheel undercarriage
Operating 46 mpm - 151 fpm
Travel 6.4 km/h - 3.9 mph
Rotor Drive System
Operates direct through a hydraulically
actuated, dry clutch driving a planetary
gear reducer.
Features
■ Heavy-duty dry clutch mounts
directly to the engine. Hydraulically
actuated by a ON/OFF switch on the
operator’s console.
■ Mechanical dry clutch consists of
trapezoid pulleys, molded high-
strength belt and a hydraulic-coupling
dry clutch. The field-proven drive
system delivers reliability and long
service life.
■ A drive train protection device
protects rotor drive system, rotor and
tools by instantly disengaging rotor
drive whenever an abrupt drop in
rotor rpm occurs.
■ Molded six-rib high tensile strength
drive belt drives the rotor through a
drum drive gear reducer located
inside the rotor mandrel.
■ Hydraulically powered automatic
drive belt tensioner prevents rotor
drive belt slippage and reduces
maintenance.
■ Upper and lower sheaves are easily
interchangeable for maximum torque
with the toughest materials and
different material sizing
requirements.
Rotor Speed:
@ 2200 engine rpm 118 rpm
