Maneuverability
Four steering modes: front, rear, crab
and coordinated enable the operator to
have complete control of the machine
position in tight milling applications.
The four-track drive provides
productive operation.
Page 8
Operator’s Station
Ergonomic design emphasizes comfort,
visibility and easy operation. Left and
right side machine controls are grouped
and conveniently located to enhance
operator visibility, productivity and
reduce fatigue.
Page 7
Collecting Conveyor
A large discharge opening and wide
collecting conveyor belt clears out the
cutter box fast. Water spray system for
lubrication, cooling and dust reduction.
Page 6 Folding Front Loading Conveyor
The PM-200 features a hydraulically
folding front loading conveyor for easy
transportation. The conveyor swings 48
degrees to the left or right to meet your
job requirements.
Page 7
Serviceability
The power-assisted engine hood opens
wide and provides exceptional access to
the engine, hydraulic pumps and daily
service points. Hydraulic rotor service
door provides convenient access to the
rotor for easy cutting tool removal and
replacement. The rotor service door
also provides easy access to the water
spray nozzles for inspection and
replacement without the need for tools.
Page 9
Rotor
Rotor with quick release conical tool
holders for quick and easy tool
replacement.
Page 6
Automatic Grade and Slope Controls
The optional grade and slope system
provides precise control of the machine
to a preset cutting depth and cross
slope. Remote mounted control boxes
allow simple operation from either the
operator’s station or ground level.
Page 8
