Milton CAT PM 200 - Manual (Page 14)

14 PM-200 specifications
Hydraulically Operated Canopy. Full
width canopy with two side extending
wings and front and rear windshields
provides optimum operator comfort and
protection. Canopy can be hydraulically
lowered for transportation.
High Pressure Washdown System. This
system uses water from the water spray
system tank to help with machine clean-
up at the end of each day’s operation.
System includes a spray wand and hose
with a quick-connect coupler.
Water Tank High Capacity Refilling
Pump. A hydraulically driven water
pump provides fast water tank refilling.
Electric Refueling Pump. An electric
powered fuel pump provides fast
refueling operations while the machine
is working without interruption.
Machine refueling can be carried out
even without starting the engine.
Additional Water Spray System for Dust
Reduction. An additional water spray
system for additional cooling of the
cutting tools in hard applications and
dust abatement. This system consists of
an extra water pump, a second spray bar
in the rotor chamber for additional
cooling of the cutting tools and extra
spray nozzles for additional dust
abatement on the collecting and loading
conveyors.
Ground Control Moldboard Pressure
Adjustment. Moldboard down pressure
can also be adjusted and varied by
ground crew.
Pneumatic Tool. Pneumatic tool with
quick-connect fitting and knockout
hammer for removing cutting tools.
Hydraulic Hammer Connection Ports.
Quick-connect fitting for hydraulic
hammer.
Two Operator Seats. Two folding
cushioned seats provide further operator
comfort during operation. Seats can be
folded to facilitate access to engine
compartment from the operator’s station.
Automatic Grade and Slope System.
Automatically controls rotor depth and
cross slope to a preset cutting depth.
System can be configured with
contacting or non-contacting grade
sensors. System also includes a
cross slope sensor to meet slope
applications/requirements in job
specifications.
Contacting wire rope grade sensor
measures side plate movement that
enables the entire length of the side plate
to become a mini averaging ski for
optimum grade matching.
Non-contacting sonic grade sensors can
be configured using one sensor per side
or the Sonic Averaging System (SAS).
The Sonic Averaging System features
three non-contacting grade sensors or a
combination of one contacting and two
non-contacting sensors that mount on
the side of the machine. Enables the
entire length of the machine to become
an averaging device.
Optional Equipment
N ote: Some options listed may be an option in some areas and standard in others. Consult your dealer for specifics.
