Milton CAT 930H - Manual (Page 13)

13
Standard VersaLink
Operating Specifications with Bucket
Coupler Buckets Pin-On Buckets
Bolt-On Cutting Edge Bolt-On Cutting Edge
Rated bucket capacity (§) m 3 2.1 2.3 2.5 2.1 2.3 2.5
yd 3 2.7 3.0 3.3 2.7 3.0 3.3
Struck capacity (§) m 3 1.7 1.9 2.1 1.7 1.9 2.1
yd 3 2.2 2.5 2.7 2.2 2.5 2.7
Bucket width mm 2550 2550 2550 2550 2550 2550
ft/in 8'4" 8'4" 8'4" 8'4" 8'4" 8'4"
10 Dump clearance at full lift and 45° discharge (§) mm 2927 2773 2727 3017 2907 2861
ft/in 9'7" 9'1" 8'11" 9'11" 9'6" 9'5"
14 Reach at full lift and 45° discharge (§) mm 1070 995 1040 966 923 969
ft/in 3'6" 3'3" 3'5" 3'2" 3'0" 3'2"
Reach at 45° discharge and 2130 mm (7'0") mm 1693 1531 1549 1663 1535 1556
clearance (§)
ft/in 5'7" 5'0" 5'1" 5'4" 5'0" 5'1"
Reach with lift arms horizontal mm 2523 2601 2666 2385 2456 2521
and bucket level ft/in 8'3" 8'6" 8'9" 7'10" 8'1" 8'3"
20 Digging depth (§) mm 152 201 201 150 157 157
in 6" 7.9" 7.9" 5.9" 6.2" 6.2"
6 Overall length mm 7570 7686 7751 7430 7507 7572
ft/in 24'10" 25'3" 25'5" 24'5" 24'8" 24'10"
13 Overall height with bucket at full raise (§) mm 5362 5383 5470 5263 5288 5354
ft/in 17'7" 17'8" 17'11" 17'3" 17'4" 17'7"
24 Loader clearance radius with bucket mm 5811 5848 5865 5760 5781 5798
in carry position (§)
ft/in 19'1" 19'2" 19'3" 18'11" 19'0" 19'0"
Static tipping load straight (§) kg 9520 9042 8951 10 007 9716 9623
lb 20,988 19,933 19,733 22,061 21,421 21,214
Static tipping load full 40° turn (§) kg 8310 7871 7785 8755 8485 8398
lb 18,321 17,352 17,164 19,302 18,707 18,514
Breakout force (§) kg 13 727 12 852 12 199 15 580 14 548 13 741
lb 30,263 28,334 26,894 34,348 32,073 30,294
Operating weight kg 13 016 13 174 13 221 12 848 12 970 13 011
lb 28,696 29,044 29,147 28,325 28,594 28,684
Static tipping and operating weights shown are for 930H with cab with A/C, optional counterweight, limited slip axles, heavy duty rear brakes,
additional guarding, sound suppression, work tool, 80 kg (176 lb) operator and Michelin 20.5 R25 L3 XHA tires.
(§) Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers (SAE), including
SAE-Standards J732 JUN92 and J742 FEB85 governing ratings.
Other Ground Engaging Tools available, consult your Cat dealer.
