990H Wheel Loader specifications
High Lift
Spade
Spade
High
HD
Bucket Type
BOCE
HDLT & BOS
Abrasion
Quarry
Heaped Capacity
m
3
8.6
8.6
8.6
8.6
yd
3
11.25
11.25
11.25
11.25
Struck Capacity
m
3
7.3
7.3
7.3
7.3
yd
3
9.5
9.5
9.5
9.5
Bucket Width
mm
4450
4450
4574
4450
ft-in
14'7"
14'7"
15'0"
14'7"
Clearance at Full Lift, 45
° Dump SAE
mm
4761
4738
4780
4737
ft-in
15'7"
15'7"
15'8"
15'7"
Tooth tip
mm
N/A
4536
4523
4487
ft-in
N/A
14'11"
14'10"
14'9"
Reach at Full Lift, 45
° Dump SAE
mm
2033
1914
2002
1916
ft-in
6'8"
6'3"
6'7"
6'3"
Tooth tip
mm
N/A
2535
2574
2566
ft-in
N/A
8'4"
8'5"
8'5"
Reach @ Level Arm and SAE
mm
4116
3967
4092
3970
Level Bucket
ft-in
13'6"
13'0"
13'5"
13'0"
Tooth tip
mm
N/A
4856
4893
4913
ft-in
N/A
15'11"
16'1"
16'1"
Digging Depth - Bucket Level
mm
190
210
210
210
inch
7.5"
8"
8"
8"
Overall Length Edge
mm
13 260
13 286
13 226
13 288
ft-in
43'6"
43'7"
43'5"
43'7"
Tooth tip
mm
N/A
13 561
13 598
13 618
ft-in
N/A
44'6"
44'7"
44'8"
Overall Height with Loaded Bucket
mm
8638
8638
8638
8638
at Max. Lift and Racked
ft-in
28'4"
28'4"
28'4"
28'4"
Clearance Circle @ Carry Edge
mm
21 189
21 123
21 305
21 124
ft-in
69'6"
69'4"
69'11"
69'4"
Tooth tip
mm
N/A
21 338
21 481
21 398
ft-in
N/A
70'0"
70'6"
70'2"
Tipping Load Str
kg
43 349
42 866
40 674
41 720
(at operating weight)
lb
95,585
94,520
89,686
91,993
35
° art
kg
38 436
37 956
35 779
36 807
lb
84,751
83,693
78,893
81,159
Breakout Force
kN
568
561
568
556
lb
127,800
126,225
127,800
125,100
Operating Weight†
kg
81 597
81 939
83 789
83 019
lb
179,881
180,676
184,755
183,057
Operation Specifications: High Lift
* DST and BOS = Double Strap Teeth and Bolt-On Segments, BOCE = Bolt-On Cutting Edge.
** Dimensions measured to end of teeth and do not conform to SAE standard.
† Static tipping load and operating weight are based on standard machine configuration with 41.25/70-39 42 PR (L-5) tires, full fuel
lubricants and operator.
†† Measured 102 mm (4 in) behind tip of cutting edge with bucket hinge pin as pivot point in accordance with SAE J732c.
NOTE: Specifications and ratings conform to all applicable standards recommended by the Society of Automotive Engineers. SAE Standard
J732 JUN92 and J742 FEB85 govern loader ratings, denoted in the text by
(§).
