S
TM
-100 & S
TM
-105
SELF-PROPELLED TELESCOPIC BOOMS
S100 3.5K 0109K. Part No. 109370
PlATFORM OPTIONS
• Steel 8 ft (2.44 m) (standard)
• Steel 6 ft (1.83 m)
• Steel 6 or 8 ft (1.83 or 2.44 m) tri-entry
• Steel 4 ft (1.22 m)**
• Steel 5 ft (1.52 m)**
JIB OPTIONS
• Non-jib
• 5 ft (1.52 m) jib boom
POWER OPTIONS
• Deutz diesel 74 hp (55 kW)
• Perkins diesel 83 hp (62 kW)
• Cummins diesel 80 hp (60 kW)
DRIVE/STEER OPTIONS
• 4WD (standard)
• 4WS (standard)
AXlE
• Extendable axles (standard)
TIRE
• Rough terrain foam-filled (standard)
EASILY CONFIGURED TO MEET
YOUR NEEDS
PRODUCTIVITY
• Platform swing gate
• Half mesh platform inserts with swing gate
• Platform top auxiliary rail
• Arc Pro 275
™ Heavy-Duty Welder package
• Welder Ready package
• Weld leads to platform
• Air line to platform
• Fire resistant hydraulic oil
• Biodegradable hydraulic oil
• Basic hostile environment kit
• Deluxe hostile environment kit
• Deluxe aircraft protection package
(6 ft platform only)
• Thumb rocker steer
• Tool tray
• Fluorescent tube caddy
• Pipe cradle (pair)
• Panel cradle package*
• Platform work lights
• Front driving lights
• Lockable platform control box covers
POWER
• AC generator packages (110V/60Hz,
3000W or 220V/50Hz, 2500W)
• Cold Weather Packages
• Arctic Packages
• Diesel scrubber/spark arrestor muffler
• Diesel spark arrestor muffler (not available
on Cummins engine)
• Retained key selector switch
OPTIONS & ACCESSORIES
Features
MEASUREMENTS
S™-100
• 106 ft (32.48 m) working height
• 75 ft (22.86 m) horizontal reach
• 750 lb (340 kg) lift capacity
S™-105
• 111 ft (34.00 m) working height
• 80 ft (24.38 m) horizontal reach
• 500 lb (227 kg) lift capacity
PRODUCTIVITY
• Self-leveling platform
• Hydraulic platform rotation
• Fully proportional Hall effect
joystick controls
• Hydraulic oil cooler
• Drive enable
• AC power cord to platform
• Horn
• Hour meter
• Tilt alarm
• Descent alarm
• Alarm package
• 360° continuous turntable rotation
• Locking low profile turntable covers
• Positive traction drive
• Two speed wheel motors
• Configurable controls to limit lift
height to 80 ft
• Ground control box cover
• Engine status display
POWER
• All engines are emissions compliant
• 12 V DC auxiliary power
• Anti-restart engine protection
• Auto engine fault shutdown
STANDARD FEATURES
155
* Available on select models
** Not available on CE machines
