3
Maneuverability
Four steering modes: front, rear, crab
and coordinated enable the operator to
have complete control of the machine
position in tight milling applications.
The four-track drive provides
productive operation.
Page 9 Operator’s Station
Ergonomic design emphasizes comfort,
visibility and easy operation. Left and
right side machine controls are grouped
and conveniently located to enhance
operator visibility, productivity and
reduce fatigue.
Page 8
Front Loading Conveyor
The PM-201 features a front loading
conveyor for greater productivity. The
conveyor swings 45 degrees to the left
or right to meet your job requirements.
Conveyor functions can be controlled
from the operator’s station or at ground
level. Conveyor features a boost
function to cast material farther for
loading long haul trucks.
Page 7 Serviceability
The power-assisted engine hood opens
wide and provides exceptional walk-in
access to the engine, hydraulic pumps
and daily service points. Hydraulic
rotor service door provides convenient
access to the rotor for easy cutting tool
removal and replacement. Water spray
nozzles are easily removed for
inspection and replacement without the
need for tools.
Page 10
Rotor Options
With a choice of three rotor options, the
PM-201 can be configured for different
applications and production
requirements.
Page 6
Automatic Grade and Slope Controls
The optional grade and slope system
provides precise control of the machine
to a preset cutting depth and cross
slope. Remote mounted control boxes
allow simple operation from either the
operator’s station or ground level.
Page 9
