PM-201 specifications
Hydraulically Operated Front Door
provides an adjustable down pressure to
prevent slabbing of the road surface in
front of the machine resulting in
optimum sizing and gradation.
Hydraulically Operated Side Plates
allow ground personnel to raise/lower
side plates to precisely place the rotor
against gutter pans or when working
near obstructions. Side plate features
replaceable bolt-on carbide wear strips
front and rear and a wear-resistant ski
for reduced wear and long service life.
Upper Conveyer Cover helps avoid
material spillage and blowing of fine
materials.
Auxiliary Rotor Drive easily rotates
the rotor for easy tool inspection and
replacement. System includes a high
torque motor and hydraulic hoses with
quick-connect couplers. A ground level
control box equipped with a toggle
switch controls the direction of rotor
rotation.
Automatic Grade and Slope System
automatically controls rotor depth and
cross slope to a preset cutting depth.
System can be configured with
contacting or non-contacting grade
sensors. System also includes a cross
slope sensor to meet slope
applications/requirements in job
specifications.
Contacting wire rope grade sensor
measures side plate movement that
enables the entire length of the side
plate to become a mini averaging ski
for optimum grade matching.
Non-contacting sonic grade sensors can
be configured using one sensor per side
or the Sonic Averaging System (SAS).
The Sonic Averaging System features
three non-contacting grade sensors or a
combination of one contacting and two
non-contacting sensors that mount on
the side of the machine. Enables the
entire length of the machine to become
an averaging device.
High Pressure Washdown System uses
water from the water spray system tank
to help with machine clean-up at the end
of each day’s operation. System includes
a spray wand and 15.2 m (50 ft) of hose
with a quick-connect coupler.
Conical Rotor features 190 point-attack
carbide-tipped tools mounted in durable
three-piece, patented quick release tool
holders. Quick release conical tool
holders have a tapered fit maintaining
tightness in holder base. Mandrel has
12 carbide-faced replaceable loading
paddles.
Breakaway Rotor features 170 point-
attack carbide-tipped tools mounted in
drive-in, knock-out tool holders. Bolt-on
breakaway design tool holders allow for
fast replacement without welding.
Weld-on Rotor features 147 point-
attack carbide-tipped tools mounted in
drive-in, knock-out tool holders. One-
piece flighting has a thickness of 51 mm
(2") to provide optimum material
movement onto collecting conveyor and
minimum wear.
Optional Equipment
N
ote: Some options listed may be an option in some areas and standard in others. Consult your dealer for specifics.
