Dimensions
All dimensions are approximate.
Load Chart and Dimensions
For more complete information on Cat products, dealer services, and industry solutiions, visit us on the web at
www.cat.com
© 2010 Caterpillar
Printed in U.S.A.
All rights reserved.
CAT, CATERPILLAR, their respective logos, “Caterpillar Yellow” and the POWER EDGE trade dress, as well as
corporate and product identity used herein, are trademarks of Caterpillar and may not be used without permission.
TL642 Telehandler
AEHQ5839-04 (03-2010)
IMPORTANT
Rated lift capacities shown are with machine
equipped with carriage and pallet forks. The
machine must be level on a firm surface with
undamaged, properly inflated tires. Machine
specifications and stability are based on rated
lift capacities at specific boom angles and
boom lengths. (If specifications are critical, the
proposed application should be discussed with
your dealer.)
DO NOT exceed rated lift capacity loads, as
unstable and dangerous machine conditions
will result.
DO NOT tip the machine forward to determine
the allowable load.
Use only JLG approved attachments
with proper material handler model/
attachment load capacity charts displayed
in the operator’s cab. OSHA requires all
rough terrain forklift operators be trained
according to OSHA 29 CFR 1910.178 (1).
Due to continuous product improvements,
machine specifications and/or equipment
changes may be made without prior
notification. This machine meets or exceeds
ANSI/ITSDF B56.6-2005 as originally
manufactured for intended applications.
TL642
221.6 in. (6.33 m)
95.5 in. (2.41 m)
94 in. (2.38 m)
128 in. (3.25 m)
16.4 in.
(416 mm)
2.41 m (95.5 in) 3.25 m (128 in)
5.63 m (221.6 in)
416 mm (16.4 in)
2.
38
m
(9
4 i
n)
8.5 m (28 ft)
9.7 m (32 ft)
10.9 m (36 ft)
12.1 m (40 ft)
13.4 m (44 ft)
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
-2.4 m (-8 ft )
1.2 m (4 ft)
0 m (0 ft)
-1.2 m (-4 ft)
3.7 m
(12 ft)
4.9 m
(16 ft)
6.1 m
(20 ft)
7.3 m
(24 ft)
8.5 m
(28 ft)
9.7 m
(32 ft)
2.4 m
(8 ft)
1.2 m
(4 ft)
0 m
(0 ft)
A
C
E
B
D
F
0°
10°
20°
30°
40°
50°
60°
70°
-9°
317 kg (700 lb)
907 kg (2,000 lb)
1361 kg (3,000 lb)
1814 kg (4,000 lb)
2722 kg (6,000 lb)
2948 kg (6,500 lb)
8.5 m (28 ft)
9.7 m (32 ft)
10.9 m (36 ft)
12.1 m (40 ft)
13.4 m (44 ft)
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
-2.4 m (-8 ft )
1.2 m (4 ft)
0 m (0 ft)
-1.2 m (-4 ft)
3.7 m
(12 ft)
4.9 m
(16 ft)
6.1 m
(20 ft)
7.3 m
(24 ft)
8.5 m
(28 ft)
9.7 m
(32 ft)
2.4 m
(8 ft)
1.2 m
(4 ft)
0 m
(0 ft)
A
C
E
B
D
F
0°
10°
20°
30°
40°
50°
60°
70°
-9°
317 kg (700 lb)
907 kg (2,000 lb)
1361 kg (3,000 lb)
1814 kg (4,000 lb)
2722 kg (6,000 lb)
2948 kg (6,500 lb) -10 10 20 30 40 50 60 70 80
-10 10 20 30 40 50 60 70 80 TL642
TL6
42
-10 10 20 30 40 50 60 70 80
-10 10 20 30 40 50 60 70 80 TL642
TL6
42
