3.7 m
(12 ft)
4.9 m
(16 ft)
2.4 m
(8 ft)
1.2 m
(4 ft)
-1.2 m
(4 ft)
0 m
(0 ft)
50°
40°
30°
20°
10°
0°
67.5°
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
1.2 m (4 ft)
-1.2 m (4 ft)
0 m (0 ft)
A
B
C
3700 kg
(8,150 lb)
3000 kg (6,600 lb) 2500 kg (5,500 lb) 2000 kg (4,400 lb) 1500 kg (3,300 lb)
3.7 m
(12 ft)
4.9 m
(16 ft)
2.4 m
(8 ft)
1.2 m
(4 ft)
-1.2 m
(4 ft)
0 m
(0 ft)
50°
40°
30°
20°
10°
0°
67.5°
7.3 m (24 ft)
6.1 m (20 ft)
4.9 m (16 ft)
3.7 m (12 ft)
2.4 m (8 ft)
1.2 m (4 ft)
-1.2 m (4 ft)
0 m (0 ft)
A
B
C
3696 kg
(8,150 lb)
2994 kg (6,600 lb) 2495 kg (5,500 lb) 1996 kg (4,400 lb) 1497 kg (3,300 lb)
TH406 Telehandler
Dimensions
All dimensions are approximate.
Load Chart and Dimensions
AEHQ5965-05 (10-2009)
2323 mm
(91.46 in)
1753 mm
(69.02 in)
2400 mm (94.48 in)
4253 mm (167.40 in)
2950 mm (116.10 in)
4621 mm (181.92 in)
409 mm
(16.10 in)
IMPORTANT
Rated lift capacities shown are with machine
equipped with carriage and pallet forks. The
machine must be level on a firm surface with
undamaged, properly inflated tires. Machine
specifications and stability are based on rated
lift capacities at specific boom angles and boom
lengths. (If specifications are critical, the proposed
application should be discussed with your dealer.)
DO NOT exceed rated lift capacity loads, as unstable
and dangerous machine conditions will result.
DO NOT tip the machine forward to determine
the allowable load.
Use only JLG approved attachments with proper
material handler model/attachment load capacity
charts displayed in the operator’s cab. OSHA
requires all rough terrain forklift operators be
trained according to OSHA 29 CFR 1910.178 (1).
Due to continuous product improvements, machine
specifications and/or equipment changes may
be made without prior notification. This machine
meets or exceeds ANSI/ITSDF B56.6-2005 as
originally manufactured for intended applications.
