128 SAL-RPM
Vishay BCcomponents Aluminum Capacitors Solid Al,
Radial Pearl Miniature
www.vishay.com For technical questions, contact: [email protected] Document Number: 28354
156 Revision: 31-Aug-09
VOLTAGE
Notes
(1) Applying the maximum RMS ripple current given in Table 2 will
cause a device temperature of 138 °C
(2) The 100 kHz values in Table 2 for other temperatures are to be
calculated with the above I
R
multipliers:
ADDITIONAL ELECTRICAL DATA
PARAMETER CONDITIONS VALUE
Voltage
Surge voltage U
s
≤ 1.15 x U
R
Reverse voltage U
rev
< 0.3 x U
R
Maximum peak AC voltage Reverse voltage applied ≤ 2 V
Maximum peak AC voltage,
without reverse voltage applied T
amb
≤ 85 °C:
at f ≤ 0.1 Hz 0.30 x U
R
at 0.1 Hz < f ≤ 1 Hz 0.45 x U
R
at 1 Hz
< f ≤ 10 Hz
0.60 x U
R
at 10 Hz
< f ≤ 50 Hz
0.65 x U
R
at f
> 50 Hz
0.80 x U
R
85
°C < T
amb
≤ 125 °C:
at f
≤ 0.1 Hz
0.15 x U
R
at 0.1 Hz
< f ≤ 1 Hz
0.22 x U
R
at 1 Hz
< f ≤ 10 Hz
0.30 x U
R
at 10 Hz
< f ≤ 50 Hz
0.32 x U
R
at f
> 50 Hz
0.40 x U
R
Inductance
Equivalent series inductance (ESL) Case sizes 10 mm x 7 mm x 3.5 mm to
10 mm x 7 mm x 5 mm typ. 9 nH to 14 nH
Case sizes 10 mm x 8 mm x 5 mm and
10 mm x 8 mm x 6 mm typ. 11 nH to 16 nH
All case sizes max. 20 nH
Dissipation
Maximum power dissipation Case sizes 10 mm x 7 mm x 3.5 mm to
10 mm x 7 mm x 5 mm P
125
= 88 mW
Case sizes 10 mm x 8 mm x 5 mm and
10 mm x 8 mm x 6 mm P
125
= 104 mW
Current
Maximum leakage current After 5 minutes at U
R
and T
amb
= 25 °C I
L5
≤ 0.025 C
R
x U
R
or 2 µA
whichever is greater; see Table 2
Typical leakage current 15 s at U
R
and T
amb
= 25
°C:
U
R
= 6.3 V to 16 V
≈ 0.2 x value stated in Table 2
U
R
= 25 V to 40 V
≈ 0.1 x value stated in Table 2
T
amb
(°C)
40
35
25
16
10
6.3
4
0
- 50 0 50 100 150 175
85 125
(1) U
C
= 125 °C
(2) U
C
= 175 °C
(1) (2)
Fig.5 Maximum permissible voltage up to T
amb
= 175 °C
RIPPLE CURRENT (I
R
)
PARAMETER
T
amb
25
°C 40 °C 65 °C 85 °C 105 °C 125 °C
I
R
multiplier 1.1 1.0 0.88 0.75 0.59 0.37
