PM800HSA060
Intellimod™ Module
Half Phase IGBT Inverter Output
800 Amperes/600 Volts
676
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
IGBT Inverter Sector
Collector Cutoff Current I
CES
V
CE
= V
CES
, T
j
= 25
°
C — — 1.0 mA
V CE = V CES , T j = 125
°
C — — 10.0 mA
Diode Forward Voltage V
FM
-I
C
= 800A, V
D
= 15V, V
CIN
= 5V — 1.9 2.8 Volts
Collector-Emitter Saturation Voltage V
CE(sat)
V
D
= 15V, V
CIN
= 0V, I
C
= 800A, — 2.0 2.7 Volts
T
j
= 25
°
C, Pulsed
V
D
= 15V, V
CIN
= 0V, I
C
= 800A, — 2.1 2.8 Volts
T j = 125
°
C, Pulsed
Inductive Load Switching Times t
on
0.5 1.4 2.5 µ S
t
rr
V
D
= 15V, V
CIN
= 0 ~ 5V — 0.15 0.3 µ S
t
C(on)
V
CC
= 300V, I
C
= 800A — 0.4 1.0
µ
S
t
off
T
j
= 125
°
C — 2.5 3.5
µ
S
t
C(off)
— 0.5 1.0
µ
S
Thermal Characteristics
Characteristic Symbol Condition Min. Typ. Max. Units
Junction to Case Thermal Resistance R
th(j-c)Q
Each IGBT — — 0.06 ° C/Watt
R
th(j-c)D
Each FWDi — — 0.09
°
C/Watt
Contact Thermal Resistance R
th(c-f)
Case to Fin Per Module, — — 0.038
°
C/Watt
Thermal Grease Applied
Recommended Conditions for Use
Characteristic Symbol Condition Value Units
Supply Voltage V
CC
Applied across C-E Terminals 0 ~ 400 Volts
V
D
Applied between V
1
-V
C
15
±
1.5 Vol
Input ON Voltage V
CIN(on)
Applied between C
1
-V
C
0 ~ 0.8 Volts
Input OFF Voltage V CIN(off) Applied between C 1 -V C 4.0 ~ V SE Volts
PWM Input Frequency f
PWM
Using Application Circuit 5 ~ 20 kHz
Minimum Dead Time t
DEAD
Input Signal
≥
3.5 µ S
