PM800HSA060
Intellimod™ Module
Half Phase IGBT Inverter Output
800 Amperes/600 Volts
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Electrical and Mechanical Characteristics, T
j
= 25
°
C unless otherwise specified
Characteristics Symbol Test Conditions Min. Typ. Max. Units
Control Sector
Over Current Trip Level Inverter Part OC -20
°
C
≤
T
j
≤
125
°
C, V
D
= 15V 1000 1350 — Amperes
Short Circuit Trip Level Inverter Part SC -20
°
C
≤
T j
≤
125
°
C, V D = 15V 1350 1870 — Amperes
Over Current Delay Time t
off(OC)
V
D
= 15V — 5 — µ S
Over Temperature Protection OT Trip Level 100 110 120
°
C
OT
R
Reset Level 85 95 105
°
C
Supply Circuit Under Voltage Protection UV Trip Level 11.5 12.0 12.5 Volts
UV R Reset Level — 12.5 — Volts
Supply Voltage V
D
Applied between V
1
-V
C
13.5 15 16.5 Volts
Circuit Current I
D
V
D
= 15V, V
CIN
= 5V — 23 30 mA
Input ON Threshold Voltage V
CIN(on)
Applied between C
1
-V
C
1.2 1.5 1.8 Volts
Input OFF Threshold Voltage V
CIN(off)
Applied between C
1
-V
C
1.7 2.0 2.3 Volts
PWM Input Frequency f
PWM
3-Ø Sinusoidal — 15 20 kHz
Arm Shoot-through Blocking Time t DEAD At IPM's Input Terminals 3.5 — —
µ
S
Fault Output Current I
FO(H)
V
D
= 15V, V
FO
= 15V — — 0.01 mA
I
FO(L)
V
D
= 15V, V
FO
= 15V — 10 15 mA
Minimum Fault Output Pulse Width t
FO
V
D
= 15V 1.0 1.8 — mS
