PM800HSA060
Intellimod™ Module
Half Phase IGBT Inverter Output
800 Amperes/600 Volts
674
Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Absolute Maximum Ratings,
T
j
= 25
°
C unless otherwise specified
Characteristics
Symbol
PM800HSA060
Units
Power Device Junction Temperature
T
j
-20 to 150
°
C
Storage Temperature
T
stg
-40 to 125
°
C
Case Operating Temperature
T
C
-20 to 100
°
C
Mounting Torque, M6 Mounting Screws (Typical)
—
25
in-lb
Mounting Torque, M8 Main Terminal Screws (Typical)
—
100
in-lb
Module Weight (Typical)
—
630
Grams
Supply Voltage Protected by OC and SC (V
D
= 13.5 ~16.5V, Inverter Part)
V
CC(prot.)
400
Volts
Isolation Voltage, AC 1 minute, 60Hz Sinusoidal
V
RMS
2500
Volts
Control Sector,
T
j
= 25
°
C unless otherwise specified
Supply Voltage Applied between (V
1
-V
C
)
V
D
20
Volts
Input Voltage Applied between (C
1
-V
C
)
V
CIN
10
Volts
Fault Output Supply Voltage (Applied between F
O
and V
NC
)
V
FO
20
Volts
Fault Output Current
I
FO
20
mA
IGBT Inverter Sector,
T
j
= 25
°
C unless otherwise specified
Collector-Emitter Voltage (V
D
= 15V, V
CIN
= 5V)
V
CES
600
Volts
Collector Current,
±
I
C
800
Amperes
Peak Collector Current,
±
I
CP
1600
Amperes
Collector Dissipation
P
C
2100
Watts
