Powerex, Inc., 200 Hillis Street, Youngwood, Pennsylvania 15697-1800 (724) 925-7272
Intellimod™ Module
Half Phase
IGBT Inverter Output
800 Amperes/600 Volts
PM800HSA060
Outline Drawing and Circuit Diagram
673
Description:
Powerex Intellimod™ Intelligent
Power Modules are isolated base
modules designed for power
switching applications operating
at frequencies to 20kHz. Built-in
control circuits provide optimum
gate drive and protection for the
IGBT and free-wheel diode
power devices.
Features:
□
Complete Output Power
Circuit
□
Gate Drive Circuit
□
Protection Logic
– Short Circuit
– Over Current
– Over Temperature
– Under Voltage
Applications:
□
Inverters
□
UPS
□
Motion/Servo Control
□
Power Supplies
Ordering Information:
Example: Select the complete
part number from the table below
-i.e. PM800HSA060 is a 600V,
800 Ampere Intellimod™ Intelligent
Power Module.
Type
Current Rating
V
CES
Amperes
Volts (x 10)
PM
800
60
Dimensions
Inches
Millimeters
A
3.46
88.0
B
3.85
98.0
C
1.16
29.5
D
2.76
70.0
E
3.15
80.0
F
2.56
65.0
G
1.34
34.0
H
0.63
16.0
J
0.63
16.1
K
1.00
25.4
L
0.20
5.1
Dimensions
Inches
Millimeters
M
1.83
46.6
N
0.28
7.0
P
0.59
15.0
Q
0.10
2.54
R
0.71
18.0
S
0.08
2.0
T
0.02 SQ
0.64 SQ
U
0.26
6.5
V
M8
M8
W
0.79
20.0
LABEL
TYP
SENS
SINK
OUT2
OUT1
TEMP
VCC
GND
FO
SR
IN
VI
FO
SR
CI
VC
C
E
C
E
1 2 3 4 5
5 FO
4 VC
3 CI
2 SR
1 V1
A
B
C
P
N
G
J
K
E
Q
F
R
D
W
S
∅
T SQ PIN
(5 PLS)
U
∅
(4 HOLES)
(2 PLS)
H
V (2 REQD)
M
L
