VS-GT100DA120U
www.vishay.com
Vishay Semiconductors
Revision: 13-Sep-13 8 Document Number: 93196
For technical questions within your region: [email protected] , [email protected] , [email protected]
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT www.vishay.com/doc?91000
ORDERING INFORMATION TABLE
CIRCUIT CONFIGURATION
- Insulated Gate Bipolar Transistor (IGBT)
- T = Trench IGBT technology
- Current rating (100 = 100 A)
- Circuit configuration (D = Single switch with antiparallel diode)
- Package indicator (A = SOT-227)
- Voltage rating (120 = 1200 V)
- Speed/type (U = Ultrafast)
Device code G T 100 D A 120 U
2
3
4
5
6
7
8
5 1 3 2 4 6 7 8
1 - Vishay Semiconductors product
VS-
3 (C)
2 (G)
1, 4 (E)
LINKS TO RELATED DOCUMENTS
Dimensions www.vishay.com/doc?95036
Packaging information www.vishay.com/doc?95037
