ACMseries - 3 -
• Zero voltage drop when unit switches over to battery backup (AC failure condition).
• Thermal and short circuit protection with auto reset.
• AC input and DC output LED indicators.
• AC fail supervision (form "C" contact).
• Battery fail and battery presence supervision (form "C" contact).
• Enclosure accommodates up to two (2) 12AH batteries.
Enclosure dimensions: 15.5"H x 12"W x 4.5"D
Installation Instructions:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only.
1. Mount unit in desired location. Mark and predrill holes in the wall to line up with the top two keyholes in the
enclosure. Install two upper fasteners and screws in the wall with the screw heads protruding. Place the enclosure’s
upper keyholes over the two upper screws, level and secure. Mark the position of the lower two holes. Remove the
enclosure. Drill the lower holes and install the three fasteners. Place the enclosure’s upper keyholes over the two
upper screws. Install the two lower screws and make sure to tighten all screws (Enclosure Dimensions, pg. 10).
Secure enclosure to earth ground. It is recommended to first review the following tables to facilitate installation:
Output Voltage and Stand-by Specifications Charts (pg. 3, 4)
Typical Application Diagram (pg. 5)
LED Diagnostics (pg. 6)
Terminal Identification Tables (pg. 7)
Hook-up Diagrams (pg. 8)
2. Set output voltage:
AL400ULACM and AL600ULACM set desired DC output voltage by setting
switch SW1 to the appropriate position on the power supply board.
AL1012ULACM is 12VDC and AL1024ULACM is 24VDC
(Output Voltage and Stand-by Specification Charts below).
3. Measure voltage before connecting devices. This helps avoid potential damage.
Output Voltage and Stand-by Specification Charts:
AL400ULACM
Voltage Switch Stand-by 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
Position Battery
12VDC SW1 - Closed 40 AH 3.5 amp / 3.5 amp .5 amp / 3.5 amp
24VDC SW1 - Open 40 AH 2.75 amp / 2.75 amp .75 amp / 2.75 amp
AL600ULACM
Voltage Switch Stand-by 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
Position Battery
12VDC SW1 - Closed 40 AH 5.5 amp / 5.5 amp .5 amp / 5.5 amp
24VDC SW1 - Open 40 AH 5.75 amp / 5.75 amp .75 amp / 5.75 amp
AL1012ULACM
Voltage Switch Stand-by 4 hr. Stand-by / 5 mins. Alarm 24 hr. Stand-by / 5 mins. Alarm
Position Battery
12VDC N/A 40 AH 9.5 amp / 9.5 amp .5 amp / 9.5 amp
