- 4 -

AL1002ULADA

6. Connect FACP output to desired AL800LGK logic board inputs, and notification appliances to desired AL800LGK

logic board outputs (see Application Guide).

Note: The 2-wire horn/strobe sync mode will only synchronize horns, horn/strobes, strobes with

synchronization capability.

7. For connection of smoke detectors, digital dialer see Optional Hookup Diagram, pg. 8.

Class A, Style Z Class B, Style W, Y, SW1 & SW2 Settings:

• For all Class B, Style W, Y, hookups SW1 & SW2 on the AL800LGK logic board must be open.

For all Class A, Style Z hookups SW1 & SW2 on the AL800LGK logic board must be closed.

Output Programming Selection Table:

Outputs must be programmed independently (OUT1 - OUT4)

Function

Switch Positions

Descriptions

ON

OFF

Input to Output
Follower Mode

1

2, 3

Output follows signal it receives from the corresponding input (i.e. FACP
Sync module - maintains synchronization of notification appliance circuit).

Temporal
Code 3 Mode

3

1, 2

Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.

Steady Mode

1, 2, 3

A steady output signal will be generated.
This mode will accept steady or pulsing input.

For the above modes Dip Switch 4 determines which Input controls
the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by input 1.
Switch 4 in the OFF position causes output(s) to be controlled by input 2.

Sync Mode Selection Table:

Function

Switch Positions

Descriptions

ON

OFF

Amseco Sync

Mode*

1, 3,

4

2

This mode is designed to work with the Amseco series of horns, strobes, and horn/

strobes to provide a means of synchronizing the Temporal-coded horns, synchro-

nizing the flash timing of the strobe, and silencing the horns of the horn/strobe

combination over a two-wire circuit while leaving strobes active.

Faraday

Sync Mode*

2, 4

1, 3

This mode is designed to work with the Faraday series of horns, strobes, and horn/

strobes to provide a means of synchronizing the Temporal-coded horns, synchroniz-

ing the flash timing of the strobe, and silencing the horns of the horn/strobe combina-

tion over a two-wire circuit while leaving strobes active.

Gentex

®

Sync Mode*

Gentex is a registered trademark
of Gentex Corporation.

1, 2,

3, 4

This mode is designed to work with the Gentex

®

series of horns, strobes, and horn/

strobes to provide a means of synchronizing the Temporal-coded horns, synchroniz-

ing the flash timing of the strobe, and silencing the horns of the horn/strobe combina-

tion over a two-wire circuit while leaving strobes active.

System Sensor

®

Sync Mode*

System Sensor is a registered
trademark of Honeywell.

1, 2, 4

3

This mode is designed to work with the System Sensor

®

series of horns, strobes, and

horn/strobes to provide a means of synchronizing the Temporal-coded horns, syn-

chronizing the one-second flash timing of the strobe, and silencing the horns of the

horn/strobe combination over a two-wire circuit while leaving strobes active.

CooperWheelock

®

Sync Mode*

CooperWheelock is a
registered trademark of
Cooper Wheelock.

2, 3, 4

1

This mode is designed to work with the CooperWheelock series of horns, strobes,

and horn/strobes to provide a means of synchronizing the Temporal-coded horns,

synchronizing the one-second flash timing of the strobe, and silencing the horns of

the horn/strobe combination over a two-wire circuit while leaving strobes active.

*Note: The AL1002ULADA will only synchronize horns, horn/strobes and strobes that contain synchronization capability.
Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.

Note: It is required to control visual notification appliances (strobes) via input 1 (IN1) and audible notification

appliances (horns) via input 2 (IN2). This allows audible notification appliances (horns) to be silenced while

visual notification appliances (strobes) continue to operate.

(AL800LGK Board)

Output Dip Switches

INPUT SELECT

TEMPORAL

STROBE SYNC

IN>OUT SYNC
