AL802ULADAJ

Class A, Style Z Class B, Style W, Y, SW1 & SW2 Settings:

• For all Class B, Style W, Y, hookups SW1 & SW2 on the AL800LGK logic board must be open.

For all Class A, Style Z hookups SW1 & SW2 on the AL800LGK logic board must be closed.
Output Programming Selection Table:

Outputs must be programmed independently (OUT1 - OUT4)

Function

Switch Positions

Descriptions

OFF

Input to Output Follower Mode

2, 3

Output follows signal it receives from the corresponding input
(i.e. FACP Sync module - maintains synchronization of
notification appliance circuit).

Temporal Code 3 Mode

1, 2

Enables Temporal Code 3 signal generation output.
This mode will accept a steady or a pulsing input.

Steady Mode

1, 2, 3

A steady output signal will be generated.
This mode will accept steady or pulsing input.

For the above modes Dip Switch 4 determines which Input controls
the corresponding output:
Switch 4 in the ON position causes output(s) to be controlled by input 1.
Switch 4 in the OFF position causes output(s) to be controlled by input 2.

Sync Mode Selection Table:

Function

Switch Positions

Descriptions

OFF

Amseco Sync
Mode*

1, 3,

This mode is designed to work with the Amseco series of horns, strobes, and
horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the flash timing of the strobe, and silencing the horns of the horn/
strobe combination over a two-wire circuit while leaving strobes active.

Faraday
Sync Mode*

2, 4

1, 3

This mode is designed to work with the Faraday series of horns, strobes, and
horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the flash timing of the strobe, and silencing the horns of the horn/
strobe combination over a two-wire circuit while leaving strobes active.

Gentex

Sync Mode*

Gentex is a registered trademark of
Gentex Corporation.

1, 2,

3, 4

This mode is designed to work with the Gentex

series of horns, strobes, and

horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the flash timing of the strobe, and silencing the horns of the horn/
strobe combination over a two-wire circuit while leaving strobes active.

System Sensor

Sync Mode*

System Sensor is a registered
trademark of Honeywell.

1, 2, 4

This mode is designed to work with the System Sensor

series of horns, strobes,

and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the one-second flash timing of the strobe, and silencing the horns
of the horn/strobe combination over a two-wire circuit while leaving
strobes active.

CooperWheelock

Sync Mode*

CooperWheelock is a
registered trademark of
CooperWheelock.

2, 3, 4

This mode is designed to work with the CooperWheelock series of horns, strobes,
and horn/strobes to provide a means of synchronizing the Temporal-coded horns,
synchronizing the one-second flash timing of the strobe, and silencing the horns
of the horn/strobe combination over a two-wire circuit while leaving
strobes active.

*Note: The AL802ULADAJ will only synchronize horns, horn/strobes and strobes that contain synchronization capability.
Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.

Note: It is required to control visual notification appliances (strobes) via input 1 [IN1] and audible notification
appliances (horns) via input 2 [IN2]. This allows audible notification appliances (horns) to be silenced while
visual notification appliances (strobes) continue to operate.

(AL800LGK Board)

Output Dip Switches

INPUT SELECT

TEMPORAL

STROBE SYNC

IN>OUT SYNC
