LED Diagnostics:
Red (DC) Green (AC) Power Supply Status
ON ON Normal operating condition.
ON OFF Loss of AC, Stand-by battery supplying power.
OFF ON No DC output.
OFF OFF Loss of AC. Discharged or no stand-by battery. No DC output.
Terminal Identification:
Terminal Legend Function/Description
L, G, N Connect 115VAC to these terminals: L to hot, N to neutral.
+ DC --
24VDC @ 8 amp continuous, 10 amp in alarm non power-limited output (UL1481). 24VDC @ 10
amp (UL294).
AC FAIL
NO, C, NC
Used to notify loss of AC power, e.g.connect to audible device or alarm panel. Relay normally
energized when AC power is present. Contact rating 1 amp @ 28VDC. AC or brownout fail is
reported within 1 minute of event. To delay reporting of up to 6 hrs., cut “AC Delay” jumper and
reset power to unit (Fig. 1a, above).
BAT FAIL
NO, C, NC
Used to indicate low battery condition, e.g. connect to alarm panel. Relay normally energized
when DC power is present. Contact rating 1 amp @ 28VDC. A removed battery is reported
within 1 minute. Battery reconnection is reported within 1 minute.
Low battery threshold: @ approximately 21VDC.
-- BAT + Stand-by battery connections. Maximum charge current 3.6 amp.
CAUTION: For continues protection against risk of fire replace fuses with the same type and rating:
Input Fuse is 5A/250V, Battery Fuse is 15A/32V
Altronix Corp.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
web site: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
