LED Diagnostics:
ACM8 & ACM8CB Access Power Controller
LED ON OFF
LED 1- LED 8 (Red) Output relay(s) energized. Output relay(s) de-energized.
Trg (Green) FACP input triggered (alarm condition). FACP normal (non-alarm condition).
Terminal Identification Tables:
ACM8 & ACM8CB Access Power Controller
Terminal Function/Description
Legend
- Power + 12VDC or 24VDC input from power supply board.
- Control + These terminals can be connected to a separate, UL listed power supply to
provide isolated operating power for the ACM8/ACM8E/ACM8CB/ACM8CBE
(jumpers J1and J2 Must be removed).
TRIGGER From normally open and/or open collector sink trigger inputs
INPUT 1- INPUT 8 (request to exit buttons, exit pir’s, etc.).
IN, GND
OUTPUT 1-OUTPUT 8 12 to 24 volts AC/DC trigger controlled outputs:
NC, C, NO, COM Fail-Safe [NC positive (+) & COM Negative (-)],
Fail-Secure [NO positive (+) & COM Negative (-)],
Auxiliary output [C positive (+) & COM Negative (-)]
(When using AC power supplies polarity need not be observed),
NC, C, NO become form “C” 5 amp 24VAC/VDC rated dry outputs when fuses are
removed (ACM8/ACM8E). Contacts shown in a non-triggered state.
FACP INTERFACE Fire Alarm Interface trigger input from FACP. Trigger inputs can be normally open,
T, + INPUT - normally closed from an FACP output circuit (Fig. 3 through 7, pg. 6).
FACP INTERFACE Form “C” relay contact rated @ 1 amp 28VDC for alarm reporting.
NC, C, NO (This output has not been evaluated by UL).
