Altronix VertiLine8i Installation Instructions - Manual (Page 2)

- 2 - Vertiline8i/Vertiline16i
Overview:
Altronix Vertiline AC Isolated CCTV Rack Mount Power Supplies provide 8 or 16 camera channels in a space saving
1U EIA 19” rack mount chassis which may be rack, wall or shelf mounted. The units feature individually selectable
24VAC and/or 28VAC power outputs.
Specifications:
Eight (8) & Sixteen (16) Output Rack Mount Configuration Reference Chart:
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should conform to
all local codes and in accordance with the National Electrical Code.
Installation Instructions:
1. Set the input voltage selector switch located on the left side of the Vertiline unit for 115VAC or
230VAC operation (Fig. 1c, pg. 4).
2. Attach mounting brackets to Vertiline unit for rack or wall mount installation (Figs. 4-5, pg. 7). Affix rubber pads to
Vertiline for shelf installation (Fig. 6, pg. 7).
3. Secure the unit in a rack, mount unit to a wall or place unit on a shelf as desired (unit should be spaced at least
3” from any video monitors).When installing the unit in a rack allow for one half of a U spacing above the unit
for ventilation.
4. Plug the grounded AC line cord (included) into the IEC 320 connector of the Vertiline unit (Fig. 1f, pg. 4).
Insert the plug end of the line cord into a grounded AC receptacle.
5. Set illuminated master power disconnect circuit breaker to the (ON) position (Fig. 3, pg. 6).
6. Select 24VAC or 28VAC power output for cameras 1-8 for Vertiline8i and Vertiline8Di or cameras 1-16 for
Vertiline16i and Vertiline16Di with the corresponding voltage adjustment switches (Fig. 1b, pg. 4).
7. Measure output voltage before connecting cameras. This helps avoid potential damage.
All terminals with common suffix (P) “1P, 2P ...” are the same polarity.
8. Set illuminated master power disconnect circuit breaker to the (OFF) position (Fig. 3, pg. 6).
Altronix
Model
Number
• Selectable 115VAC 60 Hz /230VAC 50/60 Hz input.
• Eight (8) or sixteen (16) individually selectable
24VAC or 28VAC power outputs with OFF position.
• Maximum 1 amp per output.
• Individual electronically isolated outputs.
• Eight (8) or sixteen (16) power LED indicators.
• External automotive blade fuses or
PTC protected outputs.
• Illuminated power disconnect circuit breaker with
manual reset.
• Removable terminal blocks with locking screw flange.
• Ease of installation saves time and eliminates costly labor.
• Compact 1U rack mount chassis.
• Fits standard EIA 19” rack.
• Units can be rack, wall or shelf mounted.
Vertiline8i
24VAC or
28VAC
8 amp 8 Fused -- 3 amp 3 amp
2.5 amp 1.5 amp
UL Listed for Commercial
CCTV Equipment (UL 2044).
CUL Listed - CSA Standard
C22.2 No.1-04,
Audio, Video and Similar Equipment.
Vertiline8Di
24VAC or
28VAC
8 amp 8 -- PTC 2.5 amp --
Vertiline16i
24VAC or
28VAC
16 amp 16 Fused -- 3 amp 3 amp
5 amp 2.5 amp
Vertiline16Di
24VAC or
28VAC
16 amp 16 -- PTC 2.5 amp --
Total
Output Cur
rent (P
ow
er)
OutputV
oltage (V
A
C)
Number of Isolated Outputs Output Protection Class 2 Rated P
ow
er Limited
Output Protection
Cur
rent
(max. per output) 115V
A
C 60Hz
Input Cur
rent
230V
A
C 50/60Hz
Input Cur
rent
Agenc
y Listings
Fuse Rating
