VertiLine6D
Rack Mount DC Power Supply
Rev. DSVertiLine6D_05072013
Overview
Specifications
Vertiline6D Rack Mount DC Power Supply provides eight (8) filtered and electroni-
cally regulated power outputs in a space saving 1U EIA 19” rack mount chassis.
Vertiline Rack Mount Power Supplies are also available in 12VDC and sixteen (16)
outputs configurations.
Agency Approvals
European Conformity
Input:
• 115VAC 60 Hz, 3 amp input.
Output:
• 24VDC outputs rated @ 8 amp total current max.
(1.0 amp per device, 2.5 amp max.).
• Eight (8) PTC protected power outputs.
• Filtered and electronically regulated.
Electrical:
• Operating temperature: -20º C to 49º C ambient.
• 98.27 BTU/Hr.
• System AC input VA requirement: 345VA.
Features:
• Eight (8) power LEDs.
Features (cont’d):
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19” rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625” (41.275mm) x 19.125” (486mm)
x 8.5” (216mm).
• Product weight (approx.): 8.0 lbs. (3.63 kg).
• Shipping weight (approx.): 9.3 lbs. (4.22 kg).
