T2428300E - AC Power Supply
Rev. DST2428300E - 12122012
Overview
Specifications
T2428300E AC power supply provides power for equipment, including security, access
control and surveillance devices.
T2428300E
Enclosure Dimensions
(H x W x D) (approximate)
:
12.25” (311.15mm) x 7.5” (190.5mm) x 4.5” (114.3mm)
1.25”
(31.75mm)
0.5”
(12.7mm)
0.5”
(12.7mm)
1.5”
(12.7mm)
1.25”
(31.75mm)
1.5”
(12.7mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
3.5”
(88.9mm)
1”
(25.4mm)
1”
(25.4mm)
5.75”
(146.05mm)
1”
(25.4mm)
1.13”
(28.7mm)
5.88”
(149.35mm)
0.88”
(22.35mm)
0.88”
(22.35mm)
1.11”
(28.19mm)
1.11”
(28.19mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
4.5”
(114.3mm)
7.5”
(190.5mm)
7.5”
(190.5mm)
2.5”
(63.5mm)
12”
(304.8mm)
12”
(304.8mm)
Input:
• 115VAC 50/60 Hz, 2.7 amp.
• Fused input protection rated @ 5 amp/250V.
Output:
• 24VAC @ 14 amp or 28VAC @ 12.5 amp supply
current.
Features:
• Fused input protection.
• Green grounding lead.
Electrical:
• Operating temperature: --- 20º C to 49º C ambient.
• BTU/Hr.:
- 24VAC: 172 BTU/Hr.
- 28VAC: 179.14 BTU/Hr.
• System AC input VA requirement: 310.5 VA.
Mechanical:
• Product weight (approx.): 7.2 lbs. (3.27 kg).
• Shipping weight (approx.): 8.5 lbs. (3.86 kg).
