Altronix OLS250 Data Sheet - Manual

Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
Specifications
Input:
• 115VAC, 50/60Hz, 1.9 amp.
Output:
• 24VDC output.
• 10 amp continuous supply current.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switch over to stand-by battery
when AC fails.
• Maximum charge current 0.7 amp.
Supervision:
• AC fail supervision (form “C” contacts).
Supervision (cont’d):
• Low battery supervision (form “C” contacts).
Visual Indicators:
• AC input and DC output LED indicators.
Electrical:
• Operating temperature: --- 20º C to 49º C ambient.
• BTU/Hr.: 122.84 BTU/Hr.
• System AC input VA requirement: 218.5VA.
Features:
• Power ON/OFF switch.
• Includes battery leads.
Mechanical:
• Product weight (approx.): 0.84 lbs. (0.38 kg).
• Shipping weight (approx.): 1.04 lbs. (0.47 kg).
Board Dimensions (L x W x H) (approximate) :
7.235” (183.78mm) x 4.505” (114.44mm) x 1.766” (44.87mm)
OLS250 power supply/charger converts a 115VAC, 50/60Hz input into a 24VDC
output @ 10 amp continuous supply current (see specifications). This unit has a
wide range of applications for access control and security system accessories that
require additional power.
OLS250
Off-line Switching Power Supply/Charger
Rev. DSOLS250_11152012
Overview
POWER SUPPLY
OLS200
0.362”
(9.19mm)
0.193”
(4.9mm)
3.684”
(93.57mm)
6.733”
(171.02mm)
4.505”
(114.44mm)
7.235”
(183.78mm)
0.154”
(3.91mm)
OLS250
