- 2 - eFlow104N Series
Overview:
The eFlow104N power supply/chargers convert a 120VAC / 60Hz input to a 24VDC nominal output
(see Power Supply Configuration Reference Chart and Specifications).
eFlow104N Series Power Supply Configuration Reference Chart:
Altronix Model Number
Nominal DC Outputs
Maximum Supply Current for Main and Aux. Outputs (amp) Input Rating: 120VAC, 60Hz Input Fuse Rating Battery Fuse Rating Ripple Voltage (mV) Under low battery condition Power Distribution Modiule Number of Outputs Fused Output Ratings PTC Output Ratings Accommodates up to 7AH Batteries Accommodates up to 12AH Batteries
[DC] [AUX]
24VDC Output Range (volts) 24VDC Output Range (volts)
eFlow104N
20.17-26.4 20.28-26.4 10A 4.5A 6.3A/250V 15A/32V 700 N/A 1
– – 3 –
eFlow104NX – – – 3
eFlow104N8
20.17-26.4 20.28-26.4 10A 4.5A 6.3A/250V 15A/32V 700 PD8UL 8
2.5A – 3 –
eFlow104NX8 2.5A – – 3
eFlow104N8D
20.0-26.4 20.28-26.4 10A 4.5A 6.3A/250V 15A/32V 700 PD8ULCB 8
– 2A 3 –
eFlow104NX8D – 2A – 3
eFlow104N16
20.17-26.4 20.28-26.4 10A 4.5A 6.3A/250V 15A/32V 700
PD16W
16
2.5A – 3 –
eFlow104NX16 2 - PD8UL 2.5A – – 3
eFlow104N16D
20.0-26.4 20.28-26.4 10A 4.5A 6.3A/250V 15A/32V 700
PD16WCB
16
– 2A 3 –
eFlow104NX16D 2 - PD8ULCB – 2A – 3
These units are not power-limited. If a power-limited output is required in the end-product application, the DC output from the power
supply must be connected to a separately Listed control unit or accessory board that provides power-limited outputs. The product(s)
providing the power-limited output(s) must be listed as appropriate for the particular end-product application (fire alarm, burglar
alarm, access control), and wired in accordance with the products installation instructions. Class 1 wiring methods, separation of cir-
cuits, and proper fire-rated enclosures all must be considered when connecting the DC output of the power supply to the end-product
devices. The auxiliary output of these units are power-limited..
Agency Listings:
UL Listings for US Installations:
UL 294 - UL Listed for Access Control System Units.
UL 603 - UL Listed for Power Supplies for Use with Burglar-Alarms Systems.
UL 1481 - UL Listed for Power Supplies for Fire Protective Signaling Systems.
UL Listings for Canadian Installations:
ULC-S318-96 - Power Supplies for Burglar Alarm Systems. Also suitable for Access Control.
California State Fire Marshal
(eFlow104N and eFlow104NX only)
European Conformity
Stand-by Specifications:
Battery
Burg. Applications
4 hr. Stand-by/
15 min. Alarm
Fire Applications
24 hr. Stand-by/
5 min. Alarm
Access Control
Applications
Stand-by
7AH 0.4 amp/10 amp N/A 5 Mins./10 amp
12AH 1 amp/10 amp 0.3 amp/10 amp 15 Mins./10 amp
40AH (for eFlow104NX refer to Fig. 8, pg. 10) 6 amp/10 amp 1.2 amp/10 amp Over 2 Hours/10 amp
65AH (for eFlow104NX refer to Fig. 8, pg. 10) 6 amp/10 amp 1.5 amp/10 amp Over 4 Hours/10 amp
Altronix Corp. 140 58th St. Brooklyn, NY
