R248ulcbi isolated rack mount cctv power supply

R248ULCBi provides 24VAC distributed via eight (8) isolated PTC
protected outputs for powering CCTV Cameras, heaters and other video
accessories.
Overview
Specifications
R248ULCBi
Isolated Rack Mount CCTV Power Supply
Rev. DSR248ULCBi_10252012
R248ULCBi
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Agency Approvals
European Conformity
Input:
• 115VAC, 50/60Hz, 2.7 amp.
Output:
• Eight (8) isolated PTC protected outputs.
• 24VAC @ 12.5 amp (300VA) supply current
(1.56 amp per device, 2.5 amp max.)
• Outputs are rated @ 2.5 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 114 BTU/Hr.
• System AC input VA requirement: 310.5VA.
Features:
• Eight (8) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
Mechanical:
• 2U rack mount chassis for use in standard
EIA 19” rack.
• Enclosure Dimensions (H x W x D approx.):
3.26” (83mm) x 19.125” (486mm) x 8.5” (216mm)
• Product weight (approx.): 17.2 lbs. (7.80 kg).
• Shipping weight (approx.): 18.2 lbs. (8.26 kg).
