WP1 - Outdoor Power Supply/Battery Enclosure
Rev. DSWP1 - 04162013
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
• NEMA 4/IP 65 Rated enclosure for outdoor use.
• 16 GA steel enclosure finished with heat fused polyester powder.
• Features flange mounted turn lock.
• Product weight: 9 lbs. (4.08 kg.).
• Shipping weight: 10 lbs. (4.54 kg.).
MOUNTING PANEL
GALVANIZED
CARBON STEEL SHEET
11.8”
299.7mm
4.05”
103mm
6”
152.4mm
8”
203.2mm
4.21”
107mm
12”
304.8mm
6.7”
170mm
9.84”
250mm
0.08”
2mm
14”
355.6mm
Specifications:
Enclosure Dimensions (H x W x D) (approximate) :
12” (304.8mm) x 8” (203.2mm) x 6” (152.4mm)
WP1
