PD16W, PD16WCB - UL Listed Sub-Assembly

Power Distribution Modules

Overview:

These UL Listed Sub-Assembly power distribution modules converts a single AC input into sixteen (16) individually
fused or PTC protected outputs.

Power Distribution Module Configuration Reference Chart:

Altronix

Model

Number

Number

of

Outputs

PTC Protected

Outputs

(Class 2 power limited)

Fuse

Protected

Outputs

Output Current

(max per output do not

exceed total output)

*Total output

12VDC or

24VDC

PD16W

16

---

x

2.5 amp

10 amp

PD16WCB

16

x

---

2 amp

10 amp

*Total output is limited by the total output of UL Listed power supply employed.

Specifications:

Installation Instructions:

Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all local
codes and authorities having jurisdiction. Product is intended for indoor use only and should be installed
by qualified personnel.
1. Refer to Sub Assembly Installation Instruction for mounting Rev. MS042511.
2. Connect the desired UL Listed power supply output of a suitable rating to terminals marked [INPUT] (Fig. 1a, pg. 2).
3. Measure output voltage before connecting devices. This helps avoid potential damage.
All terminals with common suffix P 1P, 2P...” are same polarity.
5. Connect each device to terminal pairs 1 to 16, marked [1P-1N thru 16P - 16N] (Fig. 1, pg. 2).
For DC applications “N” terminals are negative and “P” terminals are positive.

Note: Observe polarity.

Note: This product is a UL Listed Sub-Assembly for use with Altronix UL Listed power supplies

as indicated in the installation manuals for the power supply.

WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or

moisture. Replace fuses only with the same type and rating 3.5amp/250V.

Agency Listings:

• UL Listed Sub-Assembly for Access
Control System Units (UL 294) and
for Power Supplies for Fire Protective
Signaling Systems (UL 1481).

Input:

• 12VDC or 24VDC up to 10 amp.

Fuse Ratings:

• Fuses are rated @ 3.5A/250V.

PTC Ratings:

• PTCs are rated @ 2A/250V

Visual Indicators:

.

• Power output LED indicator (PD16W, PD16WCB).

Board Dimensions (approximate):

6”H x 5.875”W x 0.95”D (PD16W, PD16WCB)

LISTED

SECURITY

SIGNALING
