VR3T converts a 24VDC input into a regulated 12VDC output.
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
VR3T Voltage Regulator
Rev. DSVR3T _11152012
Overview
Specifications
Agency Approvals
European Conformity
Input:
• 24VDC input.
Output:
• 12VDC @ 2 amp.
• Electronically filtered and regulated output.
• Built-in overload protection.
LED Indicators:
• Power LED.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 12.28 BTU/Hr.
Applications:
• Power for 12VDC CCTV cameras and accessories,
Fiber Optic Transmitters, REX PIR’s, Prox Readers, etc.
Mechanical:
• Screw terminal blocks (wire gauge 14-20AWG).
• High impact insulated housing.
• Compact design allows for integration in a wide range
of camera housings.
• Dimensions (L x W x H approx.):
1.625” (41.28mm) x 2.375” (60.32mm) x 1” (25.4mm)
• Product weight (approx.): 0.13 lbs. (0.06 kg).
• Shipping weight (approx.): 0.15 lbs. (0.07 kg).
