Overview:
These Altronix Rack Mount CCTV Power Supplies provide 6-15VDC distributed via sixteen (16) fuse or PTC protected
outputs for powering CCTV Cameras, heaters and other video accessories.
Sixteen (16) Output Rack Mount Configuration Reference Chart:
Altronix
Model Number
Total
Output
Current
Output
Voltage
Number of
Outputs
PTC
Protected
Outputs
Fuse
Protected
Outputs
Output
Current
(max per
output)
115VAC
50/60Hz
Input
Current
R615DC1016 10 amp 6-15VDC 16 ----- x 3.5 amp 1.9 amp
R615DC1016CB 10 amp 6-15VDC 16 x ----- 2.5 amp 1.9 amp
Specifications:
Installation Instructions:
1. Unit is factory set at 12VDC. To adjust the output voltage remove the bottom cover to access trimpot on the
power supply board (Fig. 1b, pg. 3).
2. Mount unit in the desired rack location (Space unit at least 3” from any video monitors).
3. Set power switch on the back of the unit to the OFF position (Fig. 1e, pg. 3).
4. Plug power cord into a grounded 115VAC 50/60 Hz receptacle (Fig. 1d, pg. 3).
5. Set power switch to the ON (RESET) position and measure output voltage before connecting devices
(Fig. 1e, pg. 3). This helps avoiding potential damage.
6. Set power switch on the back of the unit to the OFF position (Fig. 1e, pg. 3).
7. Connect devices to the removable terminal blocks marked [1P & 1N through 16P & 16N] (Fig. 1c, pg. 3).
When wiring is completed on terminal blocks, they can be locked down by tightening screw flanges.
All terminals with common suffix (P) “1P, 2P...” are the same polarity (positive).
All terminals with common suffix (N) “1N, 2N...” are the same polarity (negative).
8. Upon completion of the wiring set power switch on the back of the unit to the ON (RESET) position (Fig. 1e, pg. 3).
9. Green power LEDs on faceplate will illuminate when AC power is present. When an output is in a trouble condition
(blown fuse or tripped PTC), the corresponding LED will not be illuminated (Fig. 1, pg. 3).
a. Blown fuse (R615DC1016) - Set power switch on the back of the unit to the OFF position (Fig. 1e, pg. 3).
Remove front faceplate to access fuses. Replace with fuses rated @ 3.5A/250VA (Altronix model # Fuse1).
b. Tripped PTC (R615DC1016CB) - To reset PTC set power switch on back of unit to the OFF position.
After approximately 30 secs. set power switch to the ON (RESET) position (Fig. 1e, pg. 3).
10. Power switch with built-in circuit breaker:
OFF position - Switch not illuminated. Outputs not powered.
RESET (ON) position - Switch illuminated. Outputs powered.
Circuit breaker tripped - Switch not illuminated. Power LEDs on faceplate are not illuminated. Outputs not powered.
To reset circuit breaker set power switch to the ON (RESET) position (Fig. 1e, pg. 3).
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or
moisture. This installation should be made by qualified service personnel and should conform to
the National Electrical Code and all local codes.
Input:
• 115VAC, 50/60Hz, 1.9 amp.
Output:
• Sixteen (16) fuse or PTC protected outputs.
• 6-15VDC @ 10 amp total output current.
(0.625 amp per device, 3.5 amp max.)
• Outputs are rated @ 3.5 amp (fused) or 2.5 amp (PTC).
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Electrical:
• System AC input VA requirement: 218.5VA.
Features:
• Sixteen (16) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
• Spare fuses provided.
Rack Dimensions (H x W x D approximate):
• 2U rack mount chassis for use in standard EIA 19” rack.
3.26” x 19.125” x 8.5” (83mm x 486mm x 216mm).
- 2 - R615DC1016 Series
