- 4 - HubWayEX16/HubWayEX32 Active Hub Unit
1 - White/Orange [VIDEO +]
2 - Orange [VIDEO -- ]
3 - White/Green [DATA +]
4 - Blue [AC 1]
5 - White/Blue [AC 2]
6 - Green [DATA -- ]
7 - White/Brown [AC 2]
8 - Brown [AC 1]
Fig. 3 - CAT-5 Structured Cable Wiring Color Codes and PIN Configurations
VIDEO BALUN/COMBINER
CAT5 + DATA-- POWER
AC
VIDEO
HubWayAv
VIDEO
AC Power
to Camera
Data to
Camera --
+ Data to
Camera
Green Power LED
12VDC Power
to Camera +
--
Red Power LED
Wire
Connectors RJ45 Jack RJ45 Jack
To BNC
Connector
of Camera
To BNC
Connector
of Camera
Structured
Cable from
HubWayEX16
or
HubWayEX32
Structured
Cable from
HubWayEX16
or
HubWayEX32
VIDEO BALUN/COMBINER
HubWayDv
CAT5 + DATA-- -- 12VDC+
--
+
Wire
Connectors
Fig. 2
Fig. 2c Fig. 2a
Fig. 2b Fig. 2d
HubWayAv passes AC voltage from pins 4, 5, 7, 8 to
terminals marked [AC Power] (Fig. 3, pg. 5). HubWayDv converts AC voltage to DC
voltage from pins 4, 5, 7, 8 to terminals marked
[-- 12VDC +] (Fig. 3, pg. 5).
HubWayAv *24VAC/28VAC *24VAC/28VAC 24VAC cameras Green
HubWayDv *24VAC/28VAC 12VDC 12VDC cameras Red
Altronix
Model
Number
O
ut
pu
t V
ol
ta
ge
to
c
am
er
a
In
pu
t V
ol
ta
ge
fr
om
H
ub
W
ay
un
it
C
am
er
a
Ty
pe
Po
w
er
L
E
D
*Based on camera load and structured cable length.
9. Connect one (1) end of a CAT-5 or higher structured cable into the RJ45 jack marked [DATA] of the
HubWayEX16/EX32 (Fig. 1e, pg. 3). Connect the opposite end of the CAT-5 or higher structured cable into the
RJ45 jack marked [DATA] of HubWayEXP (Fig. 4, pg. 5) or [DATA 1-4] of the HubSat4D/Di (Fig. 5, pg. 6).
Note: When using fixed cameras disregard this step.
Repeat steps 8 and 9 for cameras 5-8, 9-12, 13-16, 17-20, 21-24, 25-28, 29-32.
(refer to HubSat4D/Di or HubWayEXP installation instructions for camera hookups).
10. Upon completion of wiring set illuminated master power disconnect circuit breaker to the RESET (ON) position
(Fig. 5, pg. 7).
11. The video signal indicator LEDs (Red) located on the front of the HubWayEX16/EX32 will illuminate when
video signal is present (Fig. 1a, pg. 3). If any of these LEDs are not illuminated, there is no video signal for
that corresponding channel.
HubWayAv and HubWayDv Video Balun/Combiners:
