Altronix NetWayXT Data Sheet User Manual
Repeater, Netwayxt

NetWayXT repeater modules interface with NetWay midspans to extend data
(video) an additional 100m (328 ft.). A maximum range of 600m (1968 ft.) is
possible using multiple repeaters, based on camera/device port requirement.
NetWayXT -
Repeater
Rev. DSNetWayXT_04162013
Overview
Specifications
Typical Application:
Structured
Cable to
IP Camera
or next
NetWayXT
Port
Status
Power
LED
Structured
Cable from
NetWay1,
NetWay8/8M
or NetWay16/16M
www.altronix.com
NetwayXT
Repeater
IN
OUT
Power
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
Agency Approvals
European Conformity
UL/CUL Listed for Information
Technology Equipment (UL 60950-1).
®
Data:
• Extends data an additional 100m (328ft.) per port.
Functions:
• Port status LED.
• Compact insulated housing.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
Mechanical:
• Lightweight molded Acrylonitrile Butadine Styrene
enclosure is RoHS compliant.
• Compact insulated housing.
• Dimensions (W x L x H approx.):
2.5” (63.5mm) x 3.8” (96.52mm) x 1” (25.4mm)
• Product weight (approx.): 1.54 lbs. (0.7 kg.).
• Shipping weight (approx.): 1.6 lbs. (0.73 kg.).
NetWayXT
