Altronix R248UL Data Sheet User Manual
R248ul ac rack mount cctv power supply

R248UL provides 24VAC or 28VAC distributed via eight (8) fuse pro-
tected outputs for powering CCTV Cameras, heaters and other video
accessories.
R248UL
AC Rack Mount CCTV Power Supply
Rev. DSR248UL_10252012
Overview
Specifications
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Agency Approvals
European Conformity
Input:
• 115VAC, 50/60Hz, 0.85 amp.
Output:
• Eight (8) fuse protected outputs.
• 24VAC @ 3.5 amp (85VA) supply current
(0.4375 amp per device, 3.5 amp max.)
or 28VAC @ 3 amp (85VA) supply current
(0.375 amp per device, 3.5 amp max.).
• Outputs are rated @ 3.5 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 43 BTU/Hr.
• System AC input VA requirement: 97.75VA.
Features:
• Eight (8) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
• Spare fuses provided.
Mechanical:
• 2U rack mount chassis for use in standard
EIA 19” rack.
• Enclosure Dimensions (H x W x D approx.):
3.26” (83mm) x 19.125” (486mm) x 8.5” (216mm)
• Product weight (approx.): 11.8 lbs. (5.35 kg).
• Shipping weight (approx.): 12.8 lbs. (5.81 kg).
R248UL
