Altronix Maximal1R Data Sheet - Manual

Maximal1R rack mount access power controller distributes and switches power
to access control systems and accessories. It converts a 115VAC 50/60Hz input
into sixteen (16) independently controlled 12VDC or 24VDC fuse protected
outputs. Outputs are activated by an normally open (NO) or normally closed
(NC) dry trigger input from an Access Control System, Card Reader, Keypad,
Push Button, PIR, etc. This unit will route power to a variety of access con-
trol hardware devices including: Mag Locks, Electric Strikes, Magnetic Door
Holders, etc. Outputs will operate in both Fail-Safe and/or Fail-Secure modes.
The FACP Interface enables Emergency Egress, Alarm Monitoring, or may
be used to trigger other auxiliary devices. The fire alarm disconnect feature is
individually selectable for any or all of the outputs.
Input:
• 115VAC 60Hz., 1.9 amp.
• Normally closed [NC] or normally open [NO]
dry contact inputs (switch selectable).
Outputs:
• 12VDC @ 4 amp or 24VDC @ 3 amp
total output current.
• Sixteen (16) fuse protected outputs.
• Maximum current per ACM8R-M output is 2.5 amp.
• Individually selectable Mag Lock/Strike (Fail-Safe,
Fail-Secure) solid state fuse protected outputs.
• Thermal and short circuit protection with auto reset.
Fire Alarm Interface:
• Latching or Non-Latching fire alarm reset switch
individually selectable for each output.
• Remote reset capability for latching Fire Alarm
Interface mode.
• Fire Alarm disconnect input options:
a) Normally open [NO] or normally closed [NC]
dry contact input.
b)
Polarity reversal input from FACP signaling
circuit.
Visual Indicators:
• Individual Output Status LEDs located on the
front panel.
Battery Backup:
• Built-in charger for sealed lead acid or gel type
batteries (if batteries are required install
separate enclosure).
• Maximum charge current .7 amp.
• Automatic switch over to stand-by battery
when AC fails.
• Zero voltage drop when unit switches over to battery
backup (AC failure condition).
Supervision:
• AC fail supervision (form “C” contact).
• Low battery and battery presence supervision
(form “C” contact).
Additional Features:
• Removable terminal blocks with locking screw flange.
• 3-wire line cord.
• Illuminated master power disconnect circuit breaker
with manual reset.
Mechanical:
• Dimensions (HxWxD)(approx.): 3.25”(82.55mm) x
19.125”(485.78mm) x 8.5”(215.9mm)
•
Shipping Weight (approximate): 12.7 lbs (5.76kg).
Maximal1R
Rack Mount Access Power Controller
Rev. DSMaximal1R - 10312012
