Programming Instructions:
A. Setting Clock/Calendar:
Upon initial power up RLY OFF
SU 01:01
Depress SET ENTER to
SET TIME
Depress ENTER 01/01/01
SU/01:01
Enter the current date, day of week and time (military) by depressing UP and DWN to make the selection then
depress ENTER to accept.
Next select either DS (daylight savings mode) or ST (standard time mode) by depressing set until
ENTER to
SET BK
Depress ENTER to scroll until flashing cursor appears under DS (daylight savings mode) in display. To change
mode depress UP or DWN once ST (standard time mode) will appear in display. Depress ENTER to accept
correct selection.
Note: The flashing cursor denotes location of data entry selection to be made. If an entry was made in error or
requires changing, depress SET to backspace, make the correct selection and depress ENTER to accept
data and advance the cursor.
To change or program clock/calendar simply repeat the steps above.
B. Setting Events:
Depress SET until ENTER to
SET EVENT
Depress ENTER #01 OFF
SU 00:00
Depress ENTER until the flashing cursor appears under OFF in display. Now select type of event required, by
scrolling using the UP and DWN push buttons until either:
ON - Relay ON (latching mode).
OFF - Relay OFF (latching mode).
PL - Relay Pulse ( momentary).
appears in display and depressing ENTER will make selection.
When selecting the pulse mode PL01 will appear in the display. It is now necessary to assign the length of time
(duration of relay activation). The pulse can range in length from 1 second minimum to 15 seconds maximum
and is selected by using UP or DWN push buttons, then depressing ENTER to accept.
Note: If pulse duration is not selected relay output defaults to 1 second.
Next select the day of the week and time (military) by scrolling using UP and DWN push buttons and depress
ENTER to accept.
You may continue to program events by repeating the previous steps or exit programming by depressing SET.
Note: When programming additional events it is necessary to select the next consecutive event number following
the last event program to continue.
Note: When it is required to ha ve the same event repeated on two (2) or more consecutive days of the week
(Block Programming), enter the first day followed by the last day by depressing SUN through SAT.
Example:
1) Monday through Thursday depress MON followed by THURS.
2) Wednesday through Sunday depress WED followed SUN.
- 4 -
will appear in display.
will appear in display.
will appear in display.
appears in display.
appears in display.
will appear in display.
>
