Overview:
These Altronix Isolated CCTV Power Supplies provide 24VAC distributed via eight (8) or sixteen (16) fuse or
PTC protected isolated outputs for powering CCTV Cameras, heaters and other video accessories.
Isolated Power Supply Reference Chart:
ALTV248HI 24VAC 14 amp 8 - x 1.75 amp 2.7 amp
ALTV248CBHI 24VAC 14 amp 8 x - 1.75 amp 2.7 amp
ALTV248MI 24VAC 12.5 amp 8 - x 1.6 amp 2.7 amp
ALTV248CBMI 24VAC 12.5 amp 8 x - 1.6 amp 2.7 amp
ALTV2416I 24VAC 28 amp 16 - x 1.75 amp 5.4 amp
ALTV2416CBI 24VAC 28 amp 16 x - 1.75 amp 5.4 amp
Specifications:
Installation Instructions:
1. Mount unit in desired location.
2. Set power switch to OFF positon on all models (Figs. 1-3, pgs. 3-5).
3. All units are factory set for 24VAC operation.
4. Connect AC power to the black and white flying leads of the transformer(s) (Figs. 1-3, pgs. 3-5).
Use 18 AWG or larger for all power connections.
5. Measure output voltage before connecting devices. This helps avoid potential damage.
Terminals marked [1A - 8A] and [1B - 8B] are of the same polarity (phase).
6. Connect CCTV cameras to output terminals using the following procedure:
Camera 1 to output 1A & 1B. Camera 5 to output 5A & 5B.
Camera 2 to output 2A & 2B. Camera 6 to output 6A & 6B.
Camera 3 to output 3A & 3B. Camera 7 to output 7A & 7B.
Camera 4 to output 4A & 4B. Camera 8 to output 8A & 8B.
7. Set power switch on all models to the “RESET” (ON) position (Figs. 1-3, pgs. 3-5).
8. Upon completion of wiring, secure enclosure door with screws (supplied).
Caution: Equipment to be installed / serviced by authorized / trained personnel only.
Shut branch circuit power before installing / servicing equipment.
WARNING: To reduce the risk of fire or electric shock, do not expose the unit to rain or moisture.
This installation should be made by qualified service personnel and should conform to all local codes
and in accordance with the National Electrical Code.
- 2 -
Altronix
Model Number
Output Cur
rent
(max per output) Total Output Cur
rent
(P
ow
er)
Output
V
oltage
115V
A
C
50/60Hz Input Cur
rent
PTC Protected OutputsFuse Protected Outputs Number of Outputs
• Illuminated master Power ON/OFF switch
w/built in circuit breaker.
• Unit maintains camera synchronization.
• Ease of installation saves time & eliminates costly labor.
• Spare fuses included (on fuse protected models).
Enclosure Dimensions:
ALTV248MI, ALTV248CBMI: 8.5"H x 7.5"W x 3.5"D
ALTV248HI and ALTV248CBHI: 12.25"H x 7.75"W x
4.5"D
ALTV2416I and ALTV2416CBI:
13"H x 13.5"W x 3.25"D
