BC400SR - Power Supply/Battery Enclosure
Rev. DSBC400SR - 04162013
• 19 Gauge red enclosure with ample knockouts for convenient access.
• Fits four (4) 12VDC/12AH batteries.
• Product weight: 10.6 lbs. (4.81 kg).
• Shipping weight: 11.9 lbs. (5.40 kg).
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
1.5”
(38.1mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
5.0”
(127.0mm)
5.0”
(127.0mm)
1.5”
(38.1mm)
2.0”
(50.8mm)
2.0”
(50.8mm)
1.75”
(44.45mm)
1.75”
(44.45mm)
4.5”
(114.3mm) 1.25”
(31.75mm)
4.5”
(114.3mm) 1.25”
(31.75mm)
1.25”
(31.75mm)
1.25”
(31.75mm)
1.1”
(27.94mm)
1.1”
(27.94mm)
0.79”
(20.06mm)
1.1”
(27.94mm)
0.91”
(23.114mm)
0.91”
(23.114mm)
1.375”
(34.925mm)
1.125”
(28.575mm)
15.5”
(393.7mm)
4.615”
(117.22mm)
12.23”
(310.64mm)
4.615”
(117.22mm)
1.5”
(38.1mm)
1.5”
(38.1mm)
4.615”
(117.22mm)
4.615”
(117.22mm)
Specifications:
Enclosure Dimensions (H x W x D) (approximate) :
15.5” (393.7mm) x 12” (304.8mm) x 4.5” (114.3mm)
BC400SR
