Altronix TP1640 Data Sheet - Manual

Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
3.562”
(90.47mm)
3.186”
(80.92mm)
2.353”
(59.77mm)
2.658”
(67.51mm)
TP1640 Plug-In Transformer
Rev. DSTP1640_11152012
Overview
Specifications
Plug-in Transformer Diagram
Input:
• 115VAC 50/60 Hz, 0.48 amp.
Output:
• 16.5VAC/40VA (2.4 amp) output.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 20.27 BTU/Hr.
• System AC input VA requirement: 55.2VA.
Mechanical:
• Dimensions (H x W x D approx.):
3.562” (90.47mm) x 2.658” (67.51mm)
x 2.353” (59.77mm)
• Product weight (approx.): 1.25 lbs. (0.57 kg).
• Shipping weight (approx.): 1.55 lbs. (0.70 kg).
TP1640 transformer provides 16.5VAC with a total of 1.2 amp output current.
TP1640
