eBridge1CR
- 3 -
Single IP camera shown with composite video option:
Fig. 2
Fig. 2a
Fig. 3
Up to 328 ft.
Up to 328 ft.
Ethernet Switch
Up to
1500 ft.
Coax
Structured Cable
Composite Video Cable
Mounting Hole
IP Camera
(external power
required).
eBridge1CT
eBridge1CR
NVR Network
Video Server
(Head End
Equipment)
Comp. Video
Cable
To Monitor
Composite
Video
Cable
Z1409
www.altronix.com
I.T.E. 43KC
Z1409
eBridge1CR
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED
Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Coax Link LED
Coax
10/100 Base-T
Comp
.
Vide
o
Po
we
r
LE
D
Po
we
r
Input
EoC Receiver
EoC
Tr
a
nsceiver
eBridge1CT
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED
Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
Up to 328 ft.
Ethernet Switch
Up to 1500 ft.
Coax
Structured Cable
Composite Video Cable
IP Camera
Hybrid w/Sloc Technology
(external power required).
eBridge1CR
NVR Network
Video Server
(Head End
Equipment)
To Monitor
Composite
Video
Cable
Z1409
eBridge1CR
Input: 12VDC/275mA, 24VDC/110mA,
16VAC/375mA, 24VAC/200mA.
Blue LED
Coax link status.
RJ45 LEDs Yellow - Speed
Green - Activity
Green LED Power
