Altronix VertiLine24 Data Sheet - Manual

VertiLine24
UL Listed CCTV Rack Mount Power Supply
Rev. DSVertiLine24 - 12132012
Vertiline24 CCTV Rack Mount Power Supply provides 24 fuse protected power out-
puts in a space saving 1U EIA 19” rack mount chassis which may be rack, wall or
shelf mounted. This unit features individually selectable 24VAC and/or 28VAC pow-
er outputs with surge suppression. Vertiline CCTV Rack Mount Power Supplies are
also available in eight (8) and sixteen (16) output models with various power ratings.
Overview
Specifications
VertiLine24
Agency Approvals
UL Listed for Commercial CCTV Equipment (UL 2044).
Input:
• Selectable 115VAC 60 Hz or 240VAC 50/60 Hz input.
- 115VAC 60 Hz., 3 amp.
- 240VAC 50/60 Hz., 1.6 amp.
Output:
• Twenty-four (24) individually selectable 24VAC
or 28VAC power outputs with OFF position.
• 24VAC or 28VAC @ 10 amp max. total
(0.417 amp per device, 3 amp max.).
• Twenty-four (24) external blade fuse protected
outputs rated @ 3 amp.
• Main fuse rated @ 10 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• BTU/Hr.:
- 24VAC: 122.84 BTU/Hr.
- 28VAC: 143.31 BTU/Hr.
Electrical (cont’d):
• System AC input VA requirement:
115VAC: 345VA, 240VAC: 384VA.
Features:
• Twenty-four (24) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19” rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625” (41.275mm) x 19.125” (486mm)
x 8.5” (216mm)
• Product weight (approx.): 17.75 lbs. (8.05 kg).
• Shipping weight (approx.): 19.05 lbs. (8.64 kg).
