Altronix HubWay LD8CDS Data Sheet User Manual
Hubway

HubWayLD8CDS Active UTP Transceiver Hub w/Integral Camera Power
transmits UTP video, RS422/RS485 data and power over a single CAT-5
or higher structured cable. Unit provides 8 camera channels in a space sav-
ing 1U EIA 19” rack mount chassis which may be wall or shelf mounted.
Video transmission range is up to 3000 ft. max. per channel. Units are com-
patible with AC and/or DC fixed or PTZ cameras when utilizing Altronix
HubWayAv, HubWayDv or HubWayDvi Video Balun/Combiners. An option-
al HubSat4D Passive UTP Transceiver Hub with Integral Camera Power can
be used as an accessory module to transmit video from up to 4 cameras over
a single CAT-5 or higher structured cable back to the HubWayLD8CDS. In
addition, the HubSat4D provides power to these cameras locally to eliminate
the possibility of voltage drop associated with long cable runs.
Input:
• 115VAC 60Hz, 1.5 amp.
• Primary fuse is rated at 5 amp/250V.
Video:
• Eight (8) channels of video over twisted pair
up to 3000 ft. (914.4m).
• Eight (8) 75 ohm video outputs.
Data:
• RS422/RS485 data inputs.
Power:
• Individual field selectable 24VAC or 28VAC outputs.
• Unit provides up to 1 amp max. per channel not to
exceed a total of 5 amp (150VA) maximum current.
• Class 2 Rated power limited outputs.
• PTC’s are rated @ 1 amp per channel.
• Surge suppression.
Visual Indicators:
• AC input power indicator.
• Eight (8) individual video LED indicators.
Features:
• Picture and Gain control.
• Illuminated master power disconnect circuit breaker
with manual reset.
Features (cont’d):
• IEC 320 - 3-wire grounded line cord (detachable).
• Unit can be rack, wall or shelf mounted.
• 1U EIA 19” rack mount chassis.
Optional Accessories:
• Optional HubSat4D allows transmission of up to
four (4) video signals over a single CAT-5 or higher
structured cable.
• Video Balun/Combiners:
- HubWayAv2 - for use with 24VAC cameras.
- HubWayDv - for use with 12VDC cameras.
- HubWayDvi - for use with 12VDC
cameras without isolation.
Mechanical:
• Modular 1U standard EIA 19” rack mount chassis
• Enclosure Dimensions (H x W x D approx.):
1.625” (41.275mm) x 19.125” (486mm)
x
2.498” (63.45mm)
- HubWayLD8CDS: 13 lbs. (5.9 kg).
- HubWayLD82CDS: 14.2 lbs. (6.44kg).
- HubWayLD83CDS: 13.7 lbs. (6.21kg)
HubWay
®
LD8CDS Active UTP Transceiver Hub
with Integral Camera Power
Rev. DSHubWayLD8CDS - 10262012
Overview
Specifications
HubWayLD8CDS
Active UTP Transceiver Hub with Integral Camera
Power. Video Balun/Combiners not included.
HubWayLD82CDS
Active UTP Transceiver Hub with Integral Camera
Power with eight (8) HubWayAv Video Balun/
Combiners.
HubWayLD83CDS
Active UTP Transceiver Hub with Integral Camera
Power with eight (8) HubWayDv Video Balun/
Combiners.
Models
Agency Approvals
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04,
Audio, Video and Similar Equipment.
HubWayLD8CD
