T24150 AC Power Supply provides 24VAC with a total of 5.4 amp of
continuous supply current.

Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com

T24150 AC Power Supply

Rev. DST24150 - 05132013

Overview

Specifications

T24150

Input:

• 120VAC 50/60 Hz, 1.2 amp.

Output:

• 24VAC/130VA (5.4 amp).

Electrical:

• Operating temperature: --- 20º C to 49º C ambient.
• BTU/Hr.: 66.5 BTU/Hr.
• System AC input VA requirement: 144VA.

Features:

• Fused input protection rated @ 5 amp/250V.
• Green grounding lead.

Mechanical:

• Product weight (approx.): 3.5 lbs. (1.6 kg).
• Shipping weight (approx.): 4.5 lbs. (2.04 kg).

Transformer Dimensions

(H x W x D) (approximate)

:

2.82” (71.6mm) x 3.387” (86mm) x 3.05” (77.5mm)

2.82’

71.6mm

3.387’

86mm

3.05’

77.5mm

1.5’

38.1mm

2.79’

70.1mm

2.3’

58.4mm

3.013’

76.5mm
