Altronix HubWay LDH16 Data Sheet - Manual (Page 2)

1 2 3 4 CH 1-4 CH 5-8
+ DATA --
1-8
+ DATA --
9-16
5 6 7 8 9 10 11 12 CH 9-12 13 14 15 16 CH 13-16
16
PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE GAIN PICTURE AC POWER GAIN
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
17.125”
(434.97mm)
19.125”
(485.775mm)
0.95”
(24.13mm)
1.625”
(41.275mm)
8.5”
(215.9mm)
Altronix Corp. - 140 58th Street, Brooklyn, NY 11220 • 718-567-8181 • 888-258-7669 • altronix.com
Enclosure Dimensions (H x W x D approximate) :
1.625” x 19.125” x 8.5” (41.275mm x 486mm x 216mm)
