R2416ulcbi isolated rack mount cctv power supply

R2416ULCBi provides 24VAC distributed via sixteen (16) isolated PTC
protected Class 2 Rated power limited outputs for powering CCTV cam-
eras, heaters and other video accessories.
Overview
Specifications
R2416ULCBi
Isolated Rack Mount CCTV Power Supply
Rev. DSR2416ULCBi_10252012
R2416ULCBi
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Agency Approvals
European Conformity
Input:
• 115VAC, 50/60Hz, 5.4 amp.
Output:
• Sixteen (16) isolated PTC protected Class 2 Rated
power limited outputs.
• 24VAC @ 25 amp (600VA) supply current
(1.6 amp per device, 2.5 amp max.)
• Outputs are rated @ 2.5 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 227 BTU/Hr.
• System AC input VA requirement: 690VA.
Features:
• Sixteen (16) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
Mechanical:
• 2U rack mount chassis for use in standard
EIA 19” rack.
• Enclosure Dimensions (H x W x D approx.):
3.26” (83mm) x 19.125” (486mm) x 8.5” (216mm)
• Product weight (approx.): 24.4 lbs. (11.07 kg).
• Shipping weight (approx.): 25.4 lbs. (11.52 kg).
