Input:
• 115VAC 60 Hz., 4 amp.
Output:
• Sixteen (16) individually selectable 24VAC
or 28VAC power outputs with OFF position.
• 24VAC or 28VAC @ 14 amp max. total
(0.875 amp per device, 3 amp max.).
• Sixteen (16) external blade fuse protected
outputs rated @ 3 amp.
• Main fuse rated @ 15 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• BTU/Hr.:
- 24VAC: 172.0 BTU/Hr.
- 28VAC: 200.63 BTU/Hr.
• System AC input VA requirement: 460VA.
Features:
• Sixteen (16) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• IEC 320 - 3-wire grounded line cord (detachable).
• Removable terminal blocks with locking screw flange.
Mechanical:
• Units can be rack, wall or shelf mounted.
• Modular 1U standard EIA 19” rack mount chassis.
• Enclosure Dimensions (H x W x D approx.):
1.625” (41.275mm) x 19.125” (486mm)
x 8.5” (216mm).
• Product weight (approx.): 15.4 lbs. (6.99 kg).
• Shipping weight (approx.): 16.7 lbs. (7.57 kg).
VertiLine166C
UL Listed CCTV Rack Mount Power Supply
Rev. DSVertiLine166C - 12132012
Vertiline166C CCTV Rack Mount Power Supply provides 16 fuse protected power
outputs in a space saving 1U EIA 19” rack mount chassis which may be rack, wall
or shelf mounted. This unit features individually selectable 24VAC and/or 28VAC
power outputs with surge suppression. Vertiline CCTV Rack Mount Power Sup-
plies are also available in eight (8) and twenty-four (24) output models with various
power ratings.
Overview
Specifications
VertiLine166C
Agency Approvals
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-04,
Audio, Video and Similar Equipment.
