ALTV2416300ULCB3 provides 24VAC or 28VAC distributed via Sixteen (16)
Class 2 Rated PTC protected power limited outputs for powering CCTV Cameras,
heaters and other video accessories. Factory installed 3-wire line cord.
ALTV2416300ULCB3
AC CCTV Power Supply
Rev. DSALTV2416300ULCB3_10242012
Overview
ALTV2416300ULCB3
Specifications
Input:
• 115VAC, 50/60Hz, 2.7 amp.
Output:
• Sixteen (16) Class 2 Rated PTC protected
power limited outputs.
• 24VAC @ 12.5 amp (300VA) supply current
(0.781 amp per device, 2.5 amp max.)
or 28VAC @ 10 amp (280VA) supply current
(0.625 amp per device, 2.5 amp max.).
• Outputs are rated @ 2.5 amp.
• Surge suppression.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• BTU/Hr.:
- 24VAC: 153.55 BTU/Hr.
- 28VAC: 143.31 BTU/Hr.
Electrical (cont’d):
• System AC input VA requirement: 310.5VA.
Features:
• Secondary fuse rated @ 10 amp/250V.
• AC power LED.
• Power ON/OFF switch.
• Factory installed 3-wire line cord.
Mechanical:
• Enclosure Dimensions (H x W x D approx.):
13.5” (343mm) x 13” (330mm) x 3.25” (83mm)
• Product weight (approx.): 17.1 Lbs (7.756 kg)
• Shipping weight (approx.): 18.1 Lbs (8.21 kg)
UL Listed for Commercial CCTV Equipment
(UL 2044).
CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Agency Approvals
European Conformity
