Altronix R615DC416UL Data Sheet - Manual

R615DC416UL provides 6-15VDC distributed via sixteen (16) fuse
protected outputs for powering CCTV cameras, heaters and other video
accessories.
Overview
Specifications
R615DC416UL
DC Rack Mount CCTV Power Supply
Rev. R615DC416UL_10252012
R615DC416UL
UL Listed for Commercial CCTV Equipment
(UL 2044). CUL Listed - CSA Standard C22.2 No.1-98,
Audio, Video and Similar Equipment.
Agency Approvals
Input:
• 115VAC, 50/60Hz, 0.9 amp.
Output:
• Sixteen (16) fuse protected outputs.
• 6-15VDC @ 4 amp total output current.
(0.25 amp per device, 3.5 amp max.)
• Outputs are rated @ 3.5 amp.
• Filtered and electronically regulated outputs.
• Short circuit and thermal overload protection.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 12.28 - 30.71 BTU/Hr.
• System AC input VA requirement: 103.5VA.
Features:
• Sixteen (16) power LEDs.
• Illuminated master power disconnect circuit breaker
with manual reset.
• 3-wire grounded line cord.
• Removable terminal blocks with locking screw flange.
• Spare fuses provided.
Mechanical:
• 2U rack mount chassis for use in standard
EIA 19” rack.
• Enclosure Dimensions (H x W x D approx.):
3.26” (83mm) x 19.125” (486mm) x 8.5” (216mm)
• Product weight (approx.): 13.75 lbs. (6.24 kg.).
• Shipping weight (approx.): 14.75 lbs. (6.69 kg.).
