Altronix AL1012ULX Data Sheet User Manual
Al1012ulx power supply/charger

AL1012ULX
Agency Approvals
Specifications
Input:
• Input 115VAC, 60Hz, 1.9 amp.
• Input fuse rated @ 5 amp/250V.
Output:
• 12VDC output.
• 10 amp continuous supply current.
• Output fuse rated @ 15 amp/32V.
• Filtered and electronically regulated output.
• Short circuit and thermal overload protection.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Automatic switch over to stand-by battery
when AC fails.
• Maximum charge current 0.7 amp.
Supervision:
• AC fail supervision (form “C” contacts).
• Low battery supervision (form “C” contacts).
• Battery presence supervision (form “C” contacts).
Visual Indicators:
• AC input and DC output LED indicators.
Electrical:
• Operating temperature: 0º C to 49º C ambient.
• 61.42 BTU/Hr.
• System AC input VA requirement: 218.5VA.
Mechanical:
• Enclosure Dimensions (H x W x D approx.):
15.5” (393.7mm) x 12” (304.8mm) x 4.5” (114.3mm)
- Accommodates one (1) 12VDC/12AH batteries.
• Product weight (approx.): 9.3 lbs. (4.22 kg).
• Shipping weight (approx.): 10.6 lbs. (4.81 kg).
AL1012ULX is a power supply/charger that converts a 115VAC, 60Hz input into
a single 12VDC non-power limited output.
AL1012ULX
Power Supply/Charger
Rev. DSAL1012ULX_12182012
Overview
UL 294
UL Listed for Access Control
System Units.
