Enclosure dimensions, Terminal legend function/description xfmr, Terminal identification – Altronix LPS3WP12 Installation Instructions User Manual
Page 2: 12”h x 8”w x 6”d, Stand-by battery connections, 12vdc @ 2.5 amps continuous output
0.75"
0.75"
11.25"
12.00"
10.00"
8.77"
8.00"
7.40"
0.50"
2.00"
0.77"
6.00"
Terminal Identification:
Enclosure Dimensions:
12”H x 8”W x 6”D
Altronix is not responsible for any typographical errors. Product specifications are subject to change without notice.
140 58th Street, Brooklyn, New York 11220 USA, 718-567-8181, fax: 718-567-9056
website: www.altronix.com, e-mail: [email protected], Lifetime Warranty, Made in U.S.A.
IILPS3WP12 - Rev. 110801
G24H
MEMBER
Terminal Legend
Function/Description
XFMR
Low voltage AC input (16.5VAC 56VA).
- BAT +
Stand-by battery connections.
- DC +
12VDC @ 2.5 amps continuous output.
